Capresso MT500 - Line Drawings (Figures 1 -14)

FIG. 2
5
FIG. 1
1:50
A. Water Container Lid
B. GoldTone Filter
C. Removable Filter Holder with
Drip Stop
D. Water Tank
E. Water Level Indicator
F. Filter Holder Housing
(not removable)
G. Cord Storage (see Fig. 9)
H. Stainless Steel Thermal Carafe
with Lid
I. Operating Panel (see Fig. 2)
J. LED Display
K. AM/PM Indicator
Upper dot AM / lower dot PM (not shown)
L. Auto Brewing Button with green Indicator Light
M. 3-5 cups Brewing Button with green
Indicator Light
N. On/Off Coffee Brewing Button with red
Indicator Light
O. Hour (h) and Minute (m) buttons set time
and auto-on time
P. Programming Button
Q. Charcoal Filter Button with green Indicator
Light
3-5
