Preparation
ENJOY YOUR CAPTIVA DESIGNS
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents
list and hardware contents above. If any part is missing or damaged, do not attempt to assemble the product.
Contact customer service for replacement parts.
Estimated Assembly Time: 30 minutes.
Tools Required for Assembly: Wrench (not included) and Phillips Screwdriver (not included)
Hardware Contents
Components
Package Contents
A
B
C
D
E F
G
H
M5x12
15x
4x
19x3x
M6 M8
3x
M5
2x 2x
M6x12
15x
Ø5xØ12
Ø6xØ12
Ø6xØ19
M6x60
4x
I
Part Description Quantity
1 lid handle 1
2 lid air vent 1
3 Lid 1
4 lid hook 1
5 cooking grill 1
6 charcoal grill 1
7 re bowl 1
8 re bowl handle 1
9 short leg 2
Part Description Quantity
10
long leg
2
11
leg holder washer
4
12
leg holder
4
13
rebowl air vent
1
14
ash catcher holder
1
15
ash catcher handle
1
16
ash catcher
1
17
bottom wire
1
18
wheel
2
