Captiva Designs E02GR002 - Assembly Instructions

6
Assembly Instructions
Please read the assembly instructions carefully and follow the safety precautions. Allow sufcient time for
assembly. Before starting assembly, clear an area measuring approximately two to three square meters.
Remove the item from the packaging. Lay out all of the parts and any necessary tools so that they are within
easy reach.
ENJOY YOUR CAPTIVA DESIGNS
1
3
2
4
1
G
D
F
C
A
E
B
A
B
D E F G
M6x12
2x
M5x12
1x
M6
2x
M5
1x
Ø6X19
2x
Ø6X12
2x
C
Ø
5X12
1x
