Car-Interface CI-CARPLAY-NTG45 - Connection Diagram

8 / 15
www.car-interface.com
Connect to head unit
OEM Head Unit
OEM Screen
Provided 4pin LVDS Cable
CarPlay Integration for NTG 4.5
OEM 4pin
LVDS Cable
Connection Diagram
OEM Quadlock
Connector
Main Quadlock Power Cable
Connect External MIC (Optional)
See chart A below
USB Connector
USB
SD
360 / VGA
LVDS 2
LVDS 1
POWER
