It will switch to add on module UI automatically when a phone/USB stick
connected.
Operation Instruction:
 How to switch from Original to Add-on interface
Long press “BACK”
OR
OEM UI
Add on Module
Interface
DVR Video in (DIP No. 4 must be OFF )
NOTE! It will skip DVR picture if not CVBS video
signal input or DIP No.4 is “ON “ status or switch
by “BACK” button on steering wheel.
Order: OEM - Add on - DVR - OEM
Apple
CarPlay
Android
Auto
DVR
Video
Return to
Original
Screen
Mirroring
USB
Multimedia
MB SW Ver.
CP SW Ver.
Add on module UI:
