Car-Interface CI-CARPLAY-NTG5 - Connection Diagram

8 / 15
Connect to head unit
OEM Head Unit OEM Screen
Provided 4pin LVDS Cable
CarPlay Integration for NTG 5
OEM 4pin
LVDS Cable
Connection Diagram
OEM Quadlock
Connector
Main Quadlock Power Cable
Connect External MIC (Optional)
See chart A below
USB Connector
USB
SD
360 / VGA
LVDS 2
LVDS 1
POWER
