CLICK !
3. If Flash-Pairing was successful, a purple light appears for
2 seconds.
You can also “Flash-Pair” intercom channels “A” and “B” by pressing
either channel button a or b before bumping the units together.
OPTION 3: Standard “1+8” Pairing
(with cardo SHO-1, G9 and G9x models)
1. In Standby, press v for 5 seconds to enter pairing mode.
2. Repeat on the second unit.
3. If pairing was successful, a purple light appears for 2 seconds.
If your scala rider G9 already has a full list of 8 paired “1+8” Intercom
Buddies, pairing another buddy will replace the buddy that you
have not spoken to for the longest time.
5.1c PAIRED DEVICE INDICATION
You can see which units within a range of 20m are your “1+8”
Intercom Buddies.
Paired Device
Indication
In Standby, press v and for 2 seconds
If “1+8” Buddies are within range, the LEDs on both
units will turn PURPLE for 2 seconds
5.1d CALLING “1+8” INTERCOM BUDDIES
There are two ways to start an intercom call with “1+8” buddies.
OPTION 1: Voice Connect (VOX)
Speak any word loudly into the microphone. When you hear the
Voice Command tone, say the name of a ”1+8” Intercom Buddy i.e.
“John Smith”
☛
OPTION 2: Manual Mode
SAY THE NAME
CHOOSE THE NAME
(from your Buddy List):
Tap v and say the name of
the “1+8” Buddy
Press v for 2 seconds. Hear
the names of all pre-paired
“1+8” buddies.
When you hear the name of
the Buddy you wish to call,
tap v or say any word loudly
into the microphone.
To cancel Buddy List playback:
Press v for 2 seconds.
If a “1+8” intercom buddy is not in range, or moves out of range, you
have the option to set up the “IC-to-Phone” feature via the Cardo
Community, to remain in contact by diverting Intercom calls to your
mobile phones.
5.2 INTERCOM WITH CHANNELS “A” AND “B”
Start multi-party conversations using Intercom Channels “A” and
“B”. This mode is suitable for 2, 3 or 4-way calls.
English
scala rider
®
G9 / G9 PowerSet |
9
