Carel FCP/1 User Manual

FCP manual
Code +030220391 – rel 1.2 25/03/08
26
T0L lower limit of meas. range NTC-10kΩ
type and Carel supervisor address analogue var. 2
Modbus address read/write register 2
resolution and unit of measure 0.1°C
range -50.0 to T0H
default -10.0
Parameter used to set the lower limit of the range of measurement for NTC-10k
Ω probes, corresponding to 0%. The controller converts the temperature reading into
a % of the range defined by T0L and T0H. If the actual reading is less than T0L, the controller considers this to be 0%.
T0H upper limit of meas. range NTC-10kΩ
type and Carel supervisor address analogue var. 3
Modbus address read/write register 3
resolution and unit of measure 0.1°C
range T0L to 90.0
default 90.0
Parameter used to set the upper limit of the range of measurement for NTC-10k
Ω probes, corresponding to 100%. The controller converts the temperature reading
into a % of the range defined by T0L and T0H. If the actual reading is greater than T0H, the controller considers this to be 100%.
T1L lower limit of meas. range NTC-50kΩ
type and Carel supervisor address analogue var. 4
Modbus address read/write register 4
resolution and unit of measure 0.1°C
range 0.0 to T1H
default 20.0
Parameter used to set the lower limit of the range of measurement for NTC-50k
Ω probes, corresponding to 0%. The controller converts the temperature reading into
a % of the range defined by T1L and T1H.If the actual reading is less than T1L, the controller considers this to be 0%.
T1H upper limit of meas. range NTC-50kΩ
type and Carel supervisor address analogue var. 5
Modbus address read/write register 5
resolution and unit of measure 0.1°C
range T1L to 120.0
default 120.0
Parameter used to set the upper limit of the range of measurement for NTC-50k
Ω probes, corresponding to 100%. The controller converts the temperature reading
into a % of the range defined by T1L and T1H. If the actual reading is greater than T1H, the controller considers this to be 100%.
PB1T probe B1 reading
type and Carel supervisor address analogue var. (read only) 11
Modbus address read register 11
resolution and unit of measure 0.1°C
range -50.0 to 150.0
default --
Variable used to read the temperature value in °C measured by probe B1. If the probe selected is not a temperature probe, the value read is 0.
PB2T probe B2 reading
type and Carel supervisor address analogue var. 12
Modbus address read/write register 12
resolution and unit of measure 0.1°C
range -50.0 to 150.0
default --
Variable used to read the temperature value in °C measured by probe B2. If the probe selected is not a temperature probe the value read is 0.
PB3T probe B3 reading
type and Carel supervisor address analogue var. 13
Modbus address read/write register 13
resolution and unit of measure 0.1°C
range -50.0 to 150.0
default --
Variable used to read the temperature value in °C measured by probe B3.
EREV enable Reverse mode (Direct/Reverse selection)
type and Carel supervisor address digital var. 1
Modbus address read/write coil 1
resolution and unit of measure 1
range 0/1
default 0
Parameter used to select Direct or Reverse mode:
EREV=0 Direct (an increase in the value read by the probes increases the value of the output);
EREV=1 Reverse (an increase in the value read by the probes decreases the value of the output).
The parameter has no meaning if the Direct/Reverse selection is associated with dipswitch 4 (parameter DIP4)
