Carel pCO2 User Manual

11.2 Terminale utente
11.2.1 PCOT*
1. coperchio posteriore;
2. coperchio anteriore;
3. vite di fissaggio.
11.2.2 PCOI*
11.2.3 PCOT32RN*
11.2 Terminal user
11.2.1 PCOT
1. rear cover;
2. front cover;
3. fastening screw.
11.2.2 PCOI*
11.2.3 PCOT32RN
58
pCO
2
- cod. +030221835 rel. 3.0 - 18.02.03
on/off alarm enter
Graphic
Room 1
Temp
on/off alarm enter
A____
Parem
Psw
B____
Val
AL
1_ __________
2_ __________
3_ __________
4_ __________
5_ __________
on/off alarm enter
170 mm
57 mm
114 mm
170 mm
57 mm
114 mm
170 mm
57 mm
114 mm
43 mm
20
on/off alarm enter
menu I/O set prog.
?
info
Terminal
on/off alarm enter
menu I/O set prog.
?
info
Graphic
53 mm
43 mm
202 mm
177 mm
202 mm
177 mm
177 mm
75
33
dima di foratura
drilling template
71x29mm
fissaggio/ overall dimensions 91.5x36.5mm
64
71,5
Fig. 11.2.1.1
Fig. 11.2.2.1
Fig. 11.2.3.1
