11. DIMENSIONI
AVVERTENZA: tutte le quote riportate sulle figure che seguono sono
espresse in mm.
11.1 pCO
2
pCO
2
LARGE (18 moduli DIN)
pCO
2
MEDIUM (18 moduli DIN)
pCO
2
SMALL (13 moduli DIN)
11. DIMENSIONS
WARINING: all the dimensions are in mm.
11.1 pCO
2
pCO
2
LARGE (18-DIN modules)
pCO
2
MEDIUM (18-DIN modules)
pCO
2
SMALL (13-DIN modules)
57
pCO
2
- cod. +030221835 rel. 3.0 - 18.02.03
Fuse
60
110
315
45
44
built-in terminal
Fuse
60
110
315
45
44
built-in terminal
Fuse
60
110
315
45
44
built-in terminal
Fig. 11.1.1
Fig. 11.1.2
Fig. 11.1.3
