1.4 Floating suction on PVPRO
PVPRO features the Floating suction function, which can be enabled and confi gured by clicking the Floating
Suction Pressure menu from the Energy plugins, as shown in Figure 1.h.
Fig. 1.h
This can be used both on units featuring the Smooth line algorithm, and on units without this function (e.g.
IR33, MPXPRO version < 3.2). Please use this guideline to choose the most suitable option:
MPXPRO* only
Floating suction
on PVPRO with
Smooth line ag
Floating suction on
PVPRO without
Smooth line ag
Floating suction on
PVPRO without
Smooth line ag
Mix of MPXPRO*
and other utilities
Other than
MPXPRO*
utilities only
Enable Smooth line on MPXPRO
Disable Smooth line on MPXPRO
Fig. 1.i
* MPXPRO ver. 3.2 or later.
