Carel thT User Manual

14
“manuale thT” +0300077IE - rel. 1.3 - 11.04.2016
ENG
Address Type R or
R/W
Variable Description Data interpretation
11 Register R / W Day of the week
(setting)
0= Sunday
…
6= Saturday
51 Register R / W Temperature Set point Temperature value
(5,0…35,0 °C)
52 Register R / W Eco Set point Temperature value
(from 5,0 to 35,0 °C)
53 Register R / W Party Set point Temperature value
(from 5,0 to 35.0 °C)
54 Register R / W Mode button
Confi guration
Integer value
See Tab. 1.b
55 Register R / W Clock button
Confi guration
Integer value
56 Register R / W Temperature sensor
calibration
Temperature value
(from -5.0 to +5,0 °C)
57 Register R / W Humidity sensor
calibration
Humidity value (from
-10,0 to +10,0 rH%)
58 Register R / W Diff erential 0,5-1,0-1,5-2,0 °C
59 Register R / W Frost temperature From 5 to 17 °C
60 Register R / W Information menu
setting
From 0 to 5
61 Register R / W Information menu –
variable 1 value
62 Register R / W Information menu –
variable 2 value
63 Register R / W Information menu –
variable 3 value
64 Register R / W Information menu –
variable 4 value
65 Register R / W Information menu –
variable 5 value
69 Register R / W Mode button setting
70 Register R / W Fan button setting 00 Low
01 Med
02 High
03 Auto
71 Register R / W Heating button setting 00 Disabled
01 20 minutes
02 40 minutes
03 60 minutes
101 Register R / W hh Time 1 Monday-
Friday
00 - 23
102 Register R / W mm Time 1 Monday-
Friday
00 - 59
103 Register R / W Set point Time 1
Monday-Friday
5,0 – 35,0
104 Register R / W hh Time 2 Monday-
Friday
00 - 23
105 Register R / W mm Time 2 Monday-
Friday
00 - 59
106 Register R / W Set point Time 2
Monday-Friday
5,0 – 35,0
107 Register R / W hh Time 3 Monday-
Friday
00 - 23
108 Register R / W mm Time 3 Monday-
Friday
00 - 59
109 Register R / W Set point Time 3
Monday-Friday
5,0 – 35,0
110 Register R / W hh Time 4 Monday-
Friday
00 - 23
111 Register R / W mm Time 4 Monday-
Friday
00 - 59
112 Register R / W Set point Time 4
Monday-Friday
5,0 – 35,0
113 Register R / W hh Time 1 Saturday-
Sunday
00 - 23
114 Register R / W mm Time 1 Saturday-
Sunday
00 - 59
115 Register R / W Set point Time 1
Saturday- Sunday
5,0 – 35,0
116 Register R / W hh Time 2 Saturday-
Sunday
00 - 23
117 Register R / W mm Time 2 Saturday-
Sunday
00 - 59
118 Register R / W Set point Time 2
Saturday- Sunday
5,0 – 35,0
119 Register R / W hh Time 3 Saturday-
Sunday
00 - 23
120 Register R / W mm Time 3 Saturday-
Sunday
00 - 59
Address Type R or
R/W
Variable Description Data interpretation
121 Register R / W Set point Time 3
Saturday- Sunday
5,0 – 35,0
122 Register R / W hh Time 4 Saturday-
Sunday
00 - 23
123 Register R / W mm Time 4 Saturday-
Sunday
00 - 59
124 Register R / W Set point Time 4
Saturday- Sunday
5,0 – 35,0
