Cargo 211165 - Important Cautions; Technical Accuracy

211165
7
Vedpak 223_Version 1_09.2019
IV. CAUTION
During the power providing, If the short circuit protection has activated, the
PPTC fuse will jump o, and it will self-recover within about 60 seconds.
Please do not touch the testing probe when short circuit protection is activated
because high temperature generally comes with short circuit.
V. ACCURACY
DC Voltage 0–70V±(2%+2 digits)
Signal frequency and voltage Frequency 0–300KHz±(1%+1 digits)
Resistance 0-200K±(5%+3 digits)
Current 0–5A ±(3%+10 digits)
Temperature
-50°C~500°C -58°F~932°F
-50°C~-20°C (±1.5+4 digits) -58°F~-4°F (±1.5+6 digits)
-20°C~500°C (±1.5+3 digits) -4°F~932°F (±1.5+5 digits)
Positive
Negative
Load
BATTERY
