MACHINE DESCRIPTION
LEGEND
1 PRODUCT CANISTER
2 COFFEE HOPPER / PRODUCT CANISTER
3 COFFEE HOPPER
4 DECAFFEINATED DOOR
5 CARD READER
6 PEOPLE PRESENCE SENSOR
7 DISPLAY TOUCH
8 DOOR LOCK
9 RUBBER PROTECTION
10 ADJUSTABLE COFFEE DISPENSER
11 STEAM WAND
12 GROUNDS BIN
13 DRIP TRAY
Only for US market (ETL Sanitation): The equipment shall be installed with backflow protection to comply
with applicable federal, state and local codes.
