lb.00056.30 Pag. 11 26/05/10
PROGRAMMING
1) Programming the coffee dose or hot water dose for tea.
The following procedure is valid only for the coffee based keys, not for the milk based keys.
- Press key N° 7 and keep it pressed for five secon ds. The programming level is shown by the flashing light D on the keys N° 6.
- press the coffee or tea dose key to be programmed and the beverage will start being dispensed;
- press the selected dose key again when the required dose has been delivered. The dose will be stored in memory automatically.
2) Programming key N° 4 (cappuccino) dose.
The following procedure is only valid for key N° 4.
- Press key N° 7 and keep it pressed for five secon ds. The programming level is shown by the flashing light D on the keys N° 6.
- press dose key N° 4 and the coffee will start be ing dispensed;
- when the required dose of coffee has been delivered, press the key again and the coffee dose will stop. Next, the foamed milk will
start being dispensed.
- press the selected dose key again when the required dose of foamed milk has been delivered. The dose will be stored in memory
automatically.
3) Programming key N° 5 (Caffe latte) dose.
The following procedure is only valid for key N° 5.
- Press key N° 7 and keep it pressed for five secon ds. The programming level is shown by the flashing light D on the keys N° 6.
- press dose key N° 5 and the coffee will start bei ng dispensed;
- press the coffee dose key again when the required coffee dose has been delivered. A pause (no dispensing) starts;
- and once the required pause is over, press the selected key again and the hot milk will start being dispensed;
- once the required hot milk has been delivered, press the selected key again and the foamed milk will start being dispensed;
- press the selected dose key again when the required dose of foamed milk has been delivered. The dose will be stored in memory
automatically;
4) Programming key N° 6 (Latte macchiato) dose.
The following procedure is only valid for key N° 6.
- Press key N° 7 and keep it pressed for five secon ds. The programming level is shown by the flashing light D on the keys N° 6.
- press dose key N° 6 and the coffee will start bei ng dispensed;
- press the coffee dose key again when the required coffee dose has been delivered. A pause (no dispensing) starts;
- and once the required pause is over, press the selected key again and the hot milk will start being dispensed;
- once the required hot milk has been delivered, press the selected key again and the foamed milk will start being dispensed;
- press the selected dose key again when the required dose of foamed milk has been delivered. The dose will be stored in memory
automatically.
PLEASE NOTE:
For all the programmed milk based doses, the coffee dose will always be dispensed before the milk.
SPECIAL FUNCTIONS FOR MACHINE CALIBRATION
Only Assistance Service personnel authorised by CARIMALI S.P.A. are permitted to enable the use of these functions.
1) Reset machine parameters.
This function is used to reset all the counts and the water and steam values will return to the standard ones. Moreover, all the software
settings will be eliminated, and the cappuccino maker definition.
It is also possible to remove all eventual incorrect operating data from memory.
The procedure is performed as follows:
- power down the machine;
- supply power by keeping pressed keys N° 7 and N° 6 of the left-hand group until the respective light D comes on.
- power down the machine;
- power up the machine again. At this point it is ready for use.
2) Configuration for milk ( PRE ).
By enabling this configuration, the milk will be dispensed before the coffee in the cappuccino dose (key N° 4).
The procedure is carried out in the following way:
- Cut off the power supply to the machine;
- power up the machine while keeping key N° 1 press ed until the light D on key N° 6 of the same keypad comes on;
- cut off the power supply to the machine;
- power up the machine again. At this point it is ready for use.
3) Configuration for milk ( POST ).
By enabling this configuration, the milk will be dispensed after the coffee in the cappuccino dose (key N° 4).
The procedure is carried out in the following way:
- Cut off the power supply to the machine;
- power up the machine while keeping key N° 2 press ed until light D on key N° 6 of the same keypad com es on;
- cut off the power supply to the machine;
- power up the machine again. At this point it is ready for use.
