Too much atomization air pressure.
Excessive bounce-back.
Adjust gun or reduce fluid pressure.
Check distance.
Reduce air pressure and check spray
pattern.
Mix properly or apply light
coats/reduce fluid flow.
Too much fluid flow.
Change fluid nozzle for smaller size
or change air cap for different
specification air cap.
Reduce air pressure.
Runs and sags.
Check distance (normally 150-
200mm [6-8"]).
Too much air pressure.
Ball end heavy
pattern.
Thin, sandy coarse finish drying
before it flows out.
Gun too far from surface.
Mount gun at right angle to work.
Fluid flow too low.
Increase fluid flow by changing fluid
nozzle size, supply pressure or
turning needle control knob counter
clockwise.
Gun tilted at an angle.
Too much fluid flow.
Gun too far from surface.
Paint or coating too thin.
