Page | 19
Unscrew one of the small captive screws so it is loosened from the captive screw base assembly.
Insert four M4x20 screws into the captive screw base.
Figure 18 Captive screw base with captive screw
Figure 19 Four M4 x 20 screws inserted into the captive screw base
