10 VS+ Specifications
Laser module
Laser classification IEC/ EN 60825-1:2014
(Complies with 21 CFR 1040.10 and 1040.11
except for conformance with IEC 60825-1 Ed. 3.,
as described in Laser Notice No. 56, dated May 8
2019.)
Class 2*
Infrared laser module
Type InGaAs laser diode
Wavelength (typ) 905 nm
Average power 94.5 mW
Beam divergence < 2 mrads
Resolution 1 cm
Accuracy ±5 cm**
Maximum range to a passive target Up to 150 m***
Minimum range 0.5 m
Lens aperture size 18 mm - location at front of module
Visible laser module
Type InGaAsP laser diode
Wavelength 650 nm
Maximum power < 0.6 mW (continuous wave)
Lens aperture size and location 3 mm (location at front of module)
Angle measurement
Encoder type Opto-electronic encoder
Encoder accuracy 0.2°
Encoder resolution 0.1°
Mechanical range Vertical −135° to -135°
Horizontal 0° to 360°
Mechanical motion Servo-driven gear systems with manual clutches
Pitch and roll sensors
Type Triaxial, digital accelerometer
Pitch and roll accuracy ±0.2°
Pitch and roll range 360°
