Carlyle 06CC - Page 29

29
Subcoolers with R-22
Counter Flow Applications
Parallel Flow Applications
Subcoolers with R-404A/R-507
Counter Flow Applications
Parallel Flow Applications
NOTES:
1. Capacities are based on 25 F SST/110 F SDT with a
35 F liquid for R-22 and R-404A / R507 for parallel
and counter flow applications.
2. Subcooler selections are based on R-22, with an
entering liquid temperature of 110 F (43 C) direct
expanding to 25 F (-4 C) SIT and 7 F (-14 C) super-
heat on side, 1 and 110 F (43 C) liquid temperature
entering and 35 F (2 C) leaving on side 2.
Please contact Carlyle for proper sizing of subcool-
ers with HFC refrigerants.
De-Superheating Expansion Valves
MODEL NUMBER CAPACITY
(Btuh)
MASS FLOW
(lb/hr)
B8X10X7/8S 12,000 540
B8X20X7/8S 24,000 1080
B8X30X7/8S 36,000 1619
B8X40X7/8S 48,000 2159
B15X30X7/8S 60,000 2699
B25X30X1-1/8S 90,000 4048
MODEL NUMBER CAPACITY
(Btuh)
MASS FLOW
(lb/hr)
B15X10X7/8S 12,000 540
B15X20X7/8S 24,000 1080
B15X30X7/8S 36,000 1619
B15X40X7/8S 48,000 2159
B25X50X1-1/8S 60,000 2699
MODEL NUMBER CAPACITY
(Btuh)
MASS FLOW
(lb/hr)
B8X10X7/8S 11,400 543
B8X20X7/8S 15,200 602
B8X30X7/8S 25,400 972
B15X30X7/8S 44,300 1695
B25X30X1-1/8S 66,100 2530
MODEL NUMBER CAPACITY
(Btuh)
MASS FLOW
(lb/hr)
B8X10X7/8S 10,300 543
B8X20X7/8S 13,700 602
B8X30X7/8S 22,100 972
B15X30X7/8S 38,600 1695
B25X30X1-1/8S 57,600 2530
COMPRESSOR TONNAGE PART NO.
06CC016 1/2 EA11ZC011
06CC017 1/2 EA11ZC011
06CC018 1/2 EA11ZC011
06CC124 1/2 EA11ZC011
06CC125 1/2 EA11ZC011
06CC228 1/2 EA11ZC011
06CC337 1/2 EA11ZC011
06CC550 1 EA11ZC022
06CC665 1 EA11ZC022
06CC675 1 EA11ZC022
06CC899 1-1/2 EA11ZC030
