Solid-State Oil Pressure Switch
Mechanical Oil Pressure Switch
NOTE: All oil pressure switches have a 120-second time delay, manual
reset and have a switch differential setting of 8 to 11 psi cut-in (0.55 to
0.76 bar) and 4 to 8 psi (0.28 to 0.55 bar) cutout.
Crankcase Heaters
Cylinder Head Cooling Fans
NOTE: Fan package includes motor, fan, and fan guard assembly.
Compressor Spring Mounting Packages
Compressor Solid Mounting Package
NOTE: 1-1/8 OD x 1" high 1/2" diameter thru hole, use to solid mount
any Calyle
®
Compound Cooling compressor (4 spacers per compres-
sor).
Baffle Plates
NOTES:
1. The correct baffle plate must be selected for the application or
excessive pressure drop may result.
2. Two gaskets are included in each package.
3. Baffle plate is installed between compressor and discharge ser-
vice valve.
Economizer Adapter Flange
Muffler Packages
NOTE: Mufflers can be mounted vertically or horizontally.
Power Terminal Parts Connections for
HH83XB Breakers
NOTE: XB series breakers currently require customer-supplied power
wire connections at breaker. These packages contain ring terminals,
cap screws, and lock washers.
Terminal Parts Package
NOTE: Package contains 6 ring terminals to connect power wiring to
compressor terminal studs, plus 3 spare 2-hole jumper bars.
PACKAGE NO. QTY CONN VOLTAGE
06DAA660115 1 ELEC 120/240
PACKAGE NO. QTY CONN VOLTAGE
P529-2410 1 36" Lg Cap
1/4" SAE FL Nut
115/230
P529-2430 1 1/4" Male Flare 115/230
PACKAGE NO. QTY VOLTAGE WATTS
06DA660076 1 125 460
06EA660167 1 115 180
06EA660168 1 230 180
PACKAGE NO. QTY V-Ph-Hz USAGE
06DR660014 1 208/230-1-60 16-37 cfm
06ER660011 1 208/230-1-60 50-99 cfm
PACKAGE NO. QTY USAGE
06DA660057 1 16-37 cfm
06EA660089 1 50-99 cfm
PACKAGE NO. QTY USAGE
30HR070-1071 1 All Carlyle Compound
Cooling Compressors
PACKAGE NO. QTY USAGE
06DA660105 1 16-37 cfm
06EA660145 1 50-99 cfm
PACKAGE NO. USAGE
06EA660156 All Carlyle Compound
Cooling Compressors
06DA660061
(7/8" ODS Serv. Vlv.)
50-99 cfm Only
PACKAGE
NO.
QTY USAGE INLET/OUTLET
INCHES
06DA605594 1 16 cfm 5/8" ODF
06DA605604 1 17-25 cfm 7/8" ODF
06DA605614 1 28-37 cfm 1-1/8" ODF
06EA500302 1 50 cfm 1-3/8" ODF
LM10HH100 1 65-75 cfm 1-3/8" ODF
06EA500712 1 99 cfm 1-5/8" ODF
PACKAGE NO. USAGE
06EA660152 No. 1 and No. 2 Wire
06EA660153 No. 4 Wire
PACKAGE NO. QTY USE WITH USAGE
06EA900132 1 No. 6 Wire 50-99 cfm
06EA900102 1 No. 4 Wire 50-99 cfm
06EA900112 1 No. 2 Wire 50-99 cfm
06EA900122 1 No. 1/0 Wire 50-99 cfm
6.0 Compressor Accessories
