Carlyle 06CC - Page 7

7
Compressor Physical Dimensions (cont)
5.98
7.42
1 5/8 ODS
7.38
12.78
26.05
Ø0.59 on 8.88 &
11.38 Centers
17.67
8.64
1 5/8 ODS Suction
1 1/8 ODS Discharge
1.91
12.76
11.38
2X Ø0.50
0.95
12.23
16.41
1.02
1.625
Economizer Port
10.15
2X 5/16-18 UNC-2B  0.56
NOTE: Dimensions are in inches.
Fig. 3 — 06CC017, 025, 228, 337 Models
