Carlyle 06D Series User Manual

40
7/8
ODS
14.86
14.97
3.75
45°
2.192.19
8.87
10.00
2.01
17.93
3.69
5.52
12.88
6.00
2.91
SPRING MOUNTING ARRANGEMENT
TERMINAL BOX DATA
CYLINDERS: 2
CFM: 9
MODELS: 06DR109
UNLOADING AVAIL: NO
STEPS: 0
7/8
ODS
14.86
14.97
3.75
45°
2.19
8.87
10.00
2.01
17.93
3.69
5.52
12.88
6.00
2.91
COMPRESSOR FOOT
MOTOR END AND
PUMP END (TYP.)
= CUSTOMER
SUPPLIED
1.25
.19
3/8-16 x 7/8 LG
CAPSCREW
LOCKWASHER
PLATEWASHER
SPRING CUP
WELD
(TYP.)
.623
DIA. (TYP.)
.627
*
*
*
*
SPRING MOUNTING ARRANGEMENT
TERMINAL BOX DATA
CYLINDERS: 2
CFM: 8
MODELS: 06DA808
06DM808
UNLOADING AVAIL: NO
STEPS: 0
COMPRESSOR FOOT
MOTOR END AND
PUMP END (TYP.)
= CUSTOMER
SUPPLIED
1.25
.19
3/8-16 x 7/8 LG
CAPSCREW
LOCKWASHER
PLATEWASHER
SPRING CUP
WELD
(TYP.)
.623
DIA. (TYP.)
.627
*
*
*
*
NOTE: ALL DIMENSIONS ARE IN INCHES
Multiple service valve orientations are possible
06D Low Temperature Compressors
06D Medium/High Temperature Compressors
Bowman Refrigeration 206-706-3033
