9
CAUTION:
Unplug the vacuum cleaner.
The nozzle hose, located on the back of the vacuum cleaner, carries the dirt
from the nozzle to the vacuum bag. The hose also functions as the attachment
cleaning hose (on CPU-1T and CPU-2T models only).
If the hose should become clogged
1. Pull out and turn the lid of the cleaning attachment opening. Remove the
clog or blockage (Fig.1).
2. If the above step is not enough, remove hose cuff from the attachment port
inlet (Fig. 2). Turn the unit over and unscrew and remove the bottom plate
(see "How To Remove Bottom Plate."). Check nozzle inlet tube for
obstructions (Fig. 3). Clear tube and reinstall the bottom plate.
How to Clean the Nozzle Hose
Fig. 1
Fig. 2
Fig. 3
