The Carrera No. 520 Foil Shaver is a personal grooming appliance designed for cutting human hair on the face and head, offering a blend of user-friendliness, handling, and aesthetics. This appliance is suitable for use in residential, commercial, and industrial areas, adhering to safety precautions outlined in the instruction manual.

Function Description:

The foil shaver is primarily used for dry or wet shaving, maintaining a three-day beard, and trimming longer hair. It operates cordless, powered by a rechargeable Li-ion battery, providing approximately 70 minutes of use on a full charge. The device features a shaving foil, a shaving head, and a long hair trimmer for versatile grooming.

Important Technical Specifications:

Model Name: CRR520
Input: 5 V ⎓ 1 A
Battery: Li-ion, 800 mAh, 3.7 V
Operating Temperature: -10 to +40 °C
Protection Type: IPX6
Protection Class: III
Charging Time: 90 minutes for a full charge.
Cordless Use Time: Approximately 70 minutes.

Usage Features:

ON/OFF Button (6): Used to switch the appliance on and off.
Display (8): Shows the battery level in percent (01 to 100%) and indicates charging status, cleaning reminders, and lock status.
Battery Indicator (12) & Battery Symbol (13): Visually represent the battery charge level.
Plug Symbol (14): Lights up during charging and stably when the battery is nearly drained.
Transport Lock: Activated/deactivated by pressing and holding the ON/OFF button for approximately 3 seconds. The lock symbol (16) flashes briefly.
Guard (17): Used to protect the shaving head when the appliance is not in use and functions as a stubble attachment for maintaining a three-day beard.
Shaving: For optimal results, pull the skin taut with one hand and move the razor in a back-and-forth motion against the direction of hair growth, holding it at a 90° angle. Apply light pressure, increasing it slightly as the skin adapts. For wet shaving, use shaving foam; avoid gels or creams as they can contaminate the shaving head.
Three-Day Beard Maintenance: Use the guard (17) in place for a dry shave to maintain stubble.
Cutting Longer Hair/Sideburns: Slide the long hair trimmer (22) upwards. Position it on the skin and shave. After use, slide the trimmer back into its original position.
Cordless Operation: The appliance is designed for cordless use only.
Water Resistance: The appliance is not waterproof and should not be used or charged in bathtubs or showers. If it falls into water, immediately disconnect the USB-cable from the power supply with dry hands.

Maintenance Features:

Regular Cleaning: Clean the appliance regularly to prolong its lifespan. A built-in timer reminds users to clean the appliance after 30 minutes of trimming by flashing the cleaning symbol (15) on the display.
Cleaning the Shaving Foil: After each use, turn off the appliance and disconnect the USB cable. Press the release buttons (2) on the sides of the shaving head to remove the foil frame (3) with the foil. Gently tap the foil and rinse it under running water if necessary. Dry thoroughly. Remove any remaining hairs from the shaving unit with the cleaning brush (18). Replace the foil frame until it clicks into place. Do not clean the shaving foil with the brush as this may damage it.
Cleaning the Shaving Head: Regularly rinse the shaving head under running water. Remove it by pressing the release buttons (5) on the sides. Use the cleaning brush (18) to clean the area where the shaving head is inserted. Dry the head thoroughly before reinstallation.
Cleaning the Trimmer (22): Use the cleaning brush (18) to clean the trimmer.
Storage: After cleaning, place the guard (17) on the shaving head. Store the appliance in the storage bag (19) in a dark, cool place, out of children's reach. Ensure the USB cable is not tangled during storage.
Replacing Shaving Foil Frame and Cutter Block: Replace these components if the shaving foil or cutter block (20) is damaged, if shaving becomes painful, or if desired results are not achieved. Replacement is recommended approximately once a year, depending on usage intensity.
1. Press release buttons (5) to remove the shaving head.
2. Press release buttons (2) to remove the shaving foil frame from the head. Replace with a new one.
3. Hold the cutter block (20) between thumb and forefinger and carefully pull it off the razor, ensuring the spring between the cutter block and the white bracket does not fall out.
4. Guide the new cutter block into the white bracket, pushing it down until it clicks into place on the cutter block mount (21).
5. Reinstall the shaving head with the foil.
- Note: Use replacement parts specifically for Carrera shavers (purchased separately).
Safety Precautions for Cleaning: Never immerse the appliance in water. Do not use corrosive or abrasive cleaning agents, as they can damage the surface. Do not apply excessive force to the shaving foil, as it is easily damaged.
Battery Replacement: The battery can only be replaced by a qualified specialist in a service center.
Inspection: Regularly check the appliance and USB-cable for mechanical damage. Do not use if damage is found. Do not attempt to repair or modify the appliance yourself; repairs must be performed by a specialized service center.

Included Accessories:

Foil shaver
USB-Type-A to C cable
Guard
Cleaning brush
Storage bag
Instruction manual

Safety Precautions (General):

Always connect the USB-cable to the appliance first, then plug the power adapter (not included) into a power outlet.
Ensure mains voltage matches the power adapter's specifications.
Connect to an AC power source only. An RCD (residual current device) is recommended for additional protection.
Do not turn on the appliance before complete assembly and adjustment.
Do not place the working appliance on any surface, near hot gas/electric burners, or open flames.
Avoid outdoor use or areas with aerosols/flammable liquids.
Designed for household use only.
Keep away from high temperatures, direct sunlight, moisture, and other negative influences.
Do not use if dropped or externally damaged until inspected by a specialist.
Use only the specified battery type.
Do not cover the appliance, USB-cable, or adapter during use or charging.
Do not leave unattended. Switch off after use.
Not for cutting animal hair.
Prevent the USB-cable from hanging over edges or touching hot/sharp surfaces.
Avoid using non-included accessories.
Do not change accessories while the appliance is on.
Not for use by children or persons with reduced physical, sensory, or mental capabilities without supervision or instruction. Keep out of reach of children.
Remove the USB-cable from the power supply during malfunction, cleaning, prolonged disuse, thunderstorms, or after use.
Do not pull the USB-cable to disconnect.
Do not wind the cable around the appliance or carry it by the cable.
Store in a cool, dry place.

Disposal:

To protect the environment, do not dispose of the appliance or batteries with household waste. Bring them to specialized disposal points. Contact local authorities or retailers for more information.

Warranty:

The seller's warranty is 12 months from the date of sale. The service life of the product is 3 years from the date of sale, provided it is used according to the instruction manual and technical standards. The date of manufacture is coded on the device: the first two digits indicate the month, and the next four digits indicate the year.
