System Cooling Performance Data (Cont.)
Ducted Split System
53QDMT60-518 Heat Pump
380-420V/3Ph/50Hz
Indoor Conditions Outdoor Ambient Temperature
ESP
in.wg
Fan
Speed
Air
Flow
cfm
Temp. °C 35°C 43°C 46°C 52°C
DB WB
Capacity
Btu/hr
Input
W
Capacity
Btu/hr
Input
W
Capacity
Btu/hr
Input
W
Capacity
Btu/hr
Input
W
Total Sensible Total Sensible Total Sensible Total Sensible
0.36
in.wg
High
1190
21 15
44955 34345 4230 43030 34525 4440 42060 34155 4485 40115 33420 4575
24 17 46415 35905 4480 43525 34930 4710 42560 34550 4795 40615 33775 4965
27 19 48340 36930 4555 44960 35225 4785 43525 34510 4875 40650 33095 5055
32 23 50285 42255 4790 46405 41215 4975 44995 40830 5025 42185 40080 5125
Medium
1095
21 15
42710 31600 4065 40880 31765 4265 39960 31420 4310 38110 30750 4395
24 17 44095 33035 4305 41350 32140 4525 40435 31790 4605 38585 31080 4770
27 19 45925 33975 4375 42715 32405 4595 41350 31750 4680 38620 30450 4855
32 23 47775 38880 4600 44085 37920 4780 42750 37565 4825 40080 36875 4920
Low 603
21 15
39295 26860 3780 37610 27000 3965 36765 26710 4005 35065 26135 4085
24 17 40570 28080 4000 38045 27320 4210 37200 27020 4285 35500 26420 4435
27 19 42250 28880 4070 39300 27550 4275 38045 26990 4355 35530 25885 4515
21 23 43950 33045 4280 40560 32235 4445 39330 31935 4490 36870 31345 4580
0.40
in.wg
High
1159
21 15
44545 34030 4150 42635 34210 4425 41675 33845 4470 39745 33110 4560
24 17 45995 35580 4465 43130 34615 4695 42175 34240 4780 40245 33470 4950
27 19 47900 36595 4535 44550 34905 4765 43130 34200 4855 40285 32795 5035
32 23 49830 41875 4770 45985 40845 4955 44590 40460 5005 41820 39730 5105
Medium
1064
21 15
42320 31305 3985 40505 31475 4250 39595 31140 4295 37760 30460 4380
24 17 43700 32735 4290 40975 31850 4510 40070 31505 4590 38235 30795 4755
27 19 45505 33665 4355 42325 32115 4575 40975 31470 4665 38275 30175 4835
32 23 47340 38525 4580 43690 37575 4760 42365 37230 4805 39730 36555 4905
Low 710
21 15
40630 28805 3865 38885 28960 4125 38010 28650 4165 36250 28025 4250
24 17 41950 30120 4160 39335 29300 4375 38465 28980 4455 36705 28335 4610
27 19 43685 30975 4225 40630 29545 4440 39335 28950 4525 36740 27765 4690
32 23 45445 35445 4445 41940 34575 4615 40670 34250 4665 38140 33635 4755
Slow
(Reserved)
578
21 15
38935 26615 3710 37265 26755 3955 36425 26470 3995 34740 25895 4075
24 17 40200 27825 3990 37700 27070 4195 36865 26775 4270 35175 26180 4420
27 19 41865 28620 4050 38940 27295 4255 37700 26745 4335 35210 25650 4500
21 23 43555 32750 4260 40195 31940 4425 38975 31640 4470 36555 31075 4560
42QDMT60-718
38QDMT60-518
