Table 2 — LID Screens (cont)
EXAMPLE 7 — SERVICE1 DISPLAY SCREEN
To access this display from the LID default screen:
1. Press MENU
.
2. Press SERVICE
.
3. Scroll down to highlight EQUIPMENT SERVICE.
4. Press SELECT
.
5. Scroll down to highlight SERVICE1.
6. Press SELECT
.
DESCRIPTION CONFIGURABLE RANGE UNITS REFERENCE POINT NAME DEFAULT VALUE
Motor Temp Override* 150-200 (66-93) DEG F (DEG C) mt over
200 (93)
Cond Press Override 90-200 (620-1379) PSI (kPa) cp over
125 (862)
Refrig Override Delta T 2-5 (1-3) DEG F (DEG C) ref over 3D (1.6D)
Chilled Medium Water/Brine medium WATER
Brine Refrig Trippoint 8-40 (–13.3-4) DEG F (DEG C) br trip
33 (1)
Compr Discharge Alert 125-200 (52-93) DEG F (DEG C) cd alert
200 (93)
Bearing Temp Alert 165-210 (74-99) DEG F (DEG C) tb alert 210 (99)
Water Flow Verify Time 0.5-5 MIN wflow t
5
Oil Press Verify Time 15-300 SEC oilpr t 15
Water/Brine Deadband 0.5-2.0 (0.3-1.1) DEG F (DEG C) cw db
1.0 (0.6)
Recycle Restart Delta T 2.0-10.0 (1.1-5.6) DEG F (DEG C) rcycrdt 5 (2.8)
Recycle Shutdown Delta† 0.5-4.0 (.27-2.2) rcycsdt 1.0 (0.6)
Surge Limit/HGBP Option 0/1 srg hgbp
0
Select: Surge=0, HGBP=1
Surge/HGBP Delta T1 0.5-15 (0.3-8.3) DEG F (DEG C) hgb dt1
1.5 (0.8)
Surge/HGBP Delta P1 30-170 (207-1172) PSI (kPa) hgb dp1 50 (345)
Min. Load Points (T1/P1)
Surge/HGBP Delta T2 0.5-15 (0.3-8.3) DEG F (DEG C) hgb dt2
10 (5.6)
Surge/HGBP Delta P2 30-170 (207-1172) PSI (kPa) hgb dp2 85 (586)
Full Load Points (T2/P2)
Surge/HGBP Deadband 1-3 (0.6-1.6) DEG F (DEG C) hgb dp
1 (0.6)
Surge Delta Percent Amps 10-50 % surge a
25
Surge Time Period 1-5 MIN surge t 2
Demand Limit Source 0/1 dem src
0
Select: Amps=0, Load=1
Amps Correction Factor 1-8 corfact 3
Motor Rated Load Amps 1-9999 AMPS a fs
200
Motor Rated Line Voltage 1-9999 VOLTS v fs 460
Meter Rated Line KW 1-9999 kW kw fs 600
Line Frequency 0/1 HZ freq 0
Select: 0=60 Hz, 1=50 Hz
Compr Starter Type REDUCE/FULL starter REDUCE
Condenser Freeze Point –20-35 (–28.9-1.7) DEG F (DEG C) cdfreeze 34 (1)
Soft Stop Amps Threshold 40-100 % softstop 100
Stop to Start Timer† 3-50 MIN stopmtr 20
NOTE: D = delta degrees.
*Information is applicable to hermetic machines only.
†Information is applicable to open-drive machines only.
