Table 8 — LID Primary and Secondary Messages and Custom Alarm/Alert Messages
with Troubleshooting Guides (cont)
L. MACHINE ALERTS
PRIMARY MESSAGE SECONDARY MESSAGE ALARM MESSAGE/PRIMARY CAUSE ADDITIONAL CAUSE/REMEDY
RECYCLE ALERT HIGH AMPS AT SHUTDOWN High Amps at Recycle: Check guide vane drive. Check that guide vanes are closing. Check
motor amps correction calibration is cor-
rect. Check actuator for proper operation.
SENSOR FAULT ALERT LEAVING COND WATER
TEMP
Sensor Fault: Check leaving condenser water sen-
sor.
Check sensor. See sensor test
procedure.
SENSOR FAULT ALERT ENTERING COND WATER
TEMP
Sensor Fault: Check entering condenser water sen-
sor.
LOW OIL PRESSURE
ALERT
CHECK OIL FILTER Low Oil Pressure Alert: Check oil Check oil filter. Check for improper oil level
or temperature.
AUTORESTART PENDING POWER LOSS V P Power Loss: Check voltage
supply.
Check power supply if there are excessive
compressor starts occurring.
AUTORESTART PENDING LOW LINE VOLTAGE V P [VALUE] exceeded limit of [LIMIT]*. Check
voltage supply.
AUTORESTART PENDING HIGH LINE VOLTAGE V P [VALUE] exceeded limit of [LIMIT]*. Check
voltage supply.
SENSOR ALERT HIGH DISCHARGE TEMP CMPD [VALUE] exceeded limit of [LIMIT]*. Check
discharge temperature.
Discharge temperature exceeded the alert
threshold. Check entering condenser water
temperature.
SENSOR ALERT HIGH BEARING
TEMPERATURE
MTRB [VALUE] exceeded limit of [LIMIT]*. Check
thrust bearing temperature.
Thrust bearing temperature exceeded the
alert threshold. Check for closed valves, im-
proper oil level or temperatures.
CONDENSER PRESSURE
ALERT
PUMP RELAY ENERGIZED CRP High Condenser Pressure [LIMIT]*.
Pump energized to reduce pressure.
Check ambient conditions. Check con-
denser pressure for accuracy.
RECYCLE ALERT EXCESSIVE RECYCLE
STARTS
Excessive recycle starts. The machine load is too small to keep the
machine on line and there have been more
than 5 restarts in 4 hours. Increase ma-
chine load, adjust hot gas bypass, increase
RECYCLE RESTART DELTA T.
*[LIMIT] is shown on the LID as the temperature, pressure, voltage, etc., set point predefined or selected by the operator as an override, alert, or alarm condition. [VALUE]
is the actual temperature, pressure, voltage, etc., at which the control tripped.
M. SPARE SENSOR ALERT MESSAGES
PRIMARY MESSAGE SECONDARY MESSAGE ALARM MESSAGE/PRIMARY CAUSE ADDITIONAL CAUSE/REMEDY
SPARE SENSOR ALERT COMMON CHWS SENSOR Sensor Fault: Check common CHWS sensor.
Check alert temperature set points on Equipment
Service, SERVICE2 LID table.
Check sensor for accuracy if reading is not
accurate.
SPARE SENSOR ALERT COMMON CHWR SENSOR Sensor Fault: Check common CHWR
sensor.
SPARE SENSOR ALERT REMOTE RESET SENSOR Sensor Fault: Check remote reset tempera-
ture sensor.
SPARE SENSOR ALERT TEMP SENSOR — SPARE 1 Sensor Fault: Check temperature sensor —
Spare 1.
SPARE SENSOR ALERT TEMP SENSOR — SPARE 2 Sensor Fault: Check temperature sensor —
Spare 2.
SPARE SENSOR ALERT TEMP SENSOR — SPARE 3 Sensor Fault: Check temperature sensor —
Spare 3.
SPARE SENSOR ALERT TEMP SENSOR — SPARE 4 Sensor Fault: Check temperature sensor —
Spare 4.
SPARE SENSOR ALERT TEMP SENSOR — SPARE 5 Sensor Fault: Check temperature sensor —
Spare 5.
SPARE SENSOR ALERT TEMP SENSOR — SPARE 6 Sensor Fault: Check temperature sensor —
Spare 6.
SPARE SENSOR ALERT TEMP SENSOR — SPARE 7 Sensor Fault: Check temperature sensor —
Spare 7.
SPARE SENSOR ALERT TEMP SENSOR — SPARE 8 Sensor Fault: Check temperature sensor —
Spare 8.
SPARE SENSOR ALERT TEMP SENSOR — SPARE 9 Sensor Fault: Check temperature sensor —
Spare 9.
