7
2’-6"
[762mm]
3/8" MALE FLARE
RELIEF VALVE CONN.
1/2" DIA. K.O.
ELECTRICAL CONN.
(PUMPOUT POWER)
0’-9"
[229 mm]
TYPICAL
2’-8 1/2"
[826 mm]
1’-4 1/4"
[413 mm]
14’-4 1/2"
[4381mm]
0’-5 7/8"
[149mm]
(2) 1" NPT RELIEF
VALVE OUTLET (SEE FIELD
INSTALLATION NOTES)
5’-0 1/2"
[1537mm]
1’-7"
[483mm]
2’-0 5/8"
[625mm]
PRESSURE GAGE
0’-5 1/2"
[140mm]
LEVEL GAGE
0’-33/8"
[86mm]
2’-101/8"
[867mm]
2’-51/4"
[742mm]
6’-115/8"
[2124mm]
0’-97/8"
[249mm]
7’-21/4"
[2191mm]
14’-111/4"
[4553mm]
1" NPT
LIQUID CONN.
52 CU. FT. [1.47 CU. METER]
STORAGE TANK WITH PUMPOUT UNIT
3’-83/4"
[1137mm]
3’-17/16"
[951mm]
0’-9"
[229mm]
TYPICAL
3’-81/2"
[1130mm]
3’-41/2"
[1029mm]
ELECTRICAL SERVICE
ACCESS SPACE
203/4"X83/4"X41/2"
(BOTH SIDES)
3/4" NPT
PUMPOUT CONDENSER
WATER OUTLET CONN.
1/2" MALE FLARE
VAPOR CONN.
3/4" NPT
PUMPOUT CONDENSER
WATER INLET CONN.
VAPOR
1’-03/4"
[324mm]
3/8" MALE FLARE
RELIEF VALVE CONN.
1/2" DIA. K.O.
ELECTRICAL CONN.
(PUMPOUT POWER)
(FAR SIDE)
0’ - 0 15/16"
[202mm]
(FARSIDE)
0’ - 2 3/4"
[70mm]
4’ - 3 1/4"
[1302mm]
4’-1"
[1225mm]
0’-31/4"
[83mm]
0’ - 10"
[254mm]
1’-83/4"
[527mm]
4’-81/4"
[1429mm]
Fig. 5 — Storage Tank with Pumpout Unit
NOTES:
1. Denotes center of gravity.
2. Dimensions in [ ] are in millimeters.
3. The weights and center of gravity values given are for an empty
storage tank.
4. For additional information on the pumpout unit, see certified
drawings.
5. Conduit knockout is located on the side of the control box.
6. Storage tank weight: 3414 lb (1549 kg).
FRONT VIEW
TOP VIEW
LEFT SIDE VIEW
52 CU FT [1.5 CU METER] STORAGE TANK WITH PUMPOUT UNIT
