Carrier 19XR Series User Manual

8
2’- 5 3/4"
[756mm]
LEVEL GAGE
0’ - 5 1/2"
[140mm]
PRESSURE GAGE
3/8" MALE FLARE
RELIEF VALVE CONN.
1/2" DIA. K.O.
ELECTRICAL CONN.
(PUMPOUT POWER)
2’ - 0 3/8"
[619mm]
1’-7"
[483mm]
5’ - 0 1/4 "
[1530mm]
9’-10"
[2997mm]
0’ - 5 7/8 "
[149mm]
(2) 1" NPT RELIEF
VALVE OUTLET (SEE FIELD
INSTALLATION NOTES)
2’ - 4 3/4 "
[730mm]
0’-9"
[229mm]
TYPICAL
1’ - 2 3/8 "
[365mm]
0’- 3 1/2"
[89mm]
2’- 9 7/8"
[860mm]
2’- 5"
[737mm]
0’- 9 7/8"
[249mm]
4’- 9 1/2"
[1451mm]
6’- 4 3/16"
[1935mm]
1" NPT
LIQUID CONN.
0’- 9"
[229mm]
TYPICAL
3’- 1 1/4"
[946mm]
3’- 4 5/8"
[1032mm]
3’- 4 7/8"
[1038mm]
2’- 9 9/16"
[852mm]
VAPOR
3/4" NPT
PUMPOUT CONDENSER
WATER INLET CONN.
1/2" MALE FLARE
VAPOR CONN.
3/4" NPT
PUMPOUT CONDENSER
WATER OUTLET CONN.
ELECTRICAL SERVICE
ACCESS SPACE
20 3/4" X 8 3/4" X 4 1/2"
(BOTH SIDES)
28 CU.FT. [.79 CU. METER]
STORGE TANK WITH PUMPOUT UNIT
10’- 5 "
[3175mm]
Fig. 5 — Storage Tank with Pumpout Unit (cont)
NOTES:
1. Denotes center of gravity.
2. Dimensions in [ ] are in millimeters.
3. The weights and center of gravity values given are for an empty
storage tank.
4. For additional information on the pumpout unit, see certified
drawings.
5. Conduit knockout is located on the side of the control box.
6. Storage tank weight: 2334 lb (1059 kg).
TOP VIEW
FRONT VIEW
1’-0 3/4"
[324mm]
3/8" MALE FLARE
RELIEF VALVE CONN.
1/2" DIA. K.O.
ELECTRICAL CONN.
(PUMPOUT POWER)
(FAR SIDE)
3’- 11 3/8"
[1203mm]
3’- 9"
[1143mm]
0’- 3 1/4"
[83mm]
0’- 10"
[254mm]
1’- 7 7/8"
[505mm]
4’- 4 1/4"
[1327mm]
0’- 2 3/4"
[70mm]
0’- 7 15/16"
[202mm]
(FARSIDE)
28 CU FT [0.8 CU METER] STORAGE TANK WITH PUMPOUT UNIT
LEFT SIDE VIEW
