12
Table 7 — 19XR Compressor and Motor Weights* — High-Efficiency Motors
Two-Stage Compressor Frame Size 6, 60 Hz
*Total compressor weight is the sum of the compressor aerody-
namic components (compressor weight column), stator, rotor, and
end bell cover weights.
†Compressor aerodynamic component weight only, motor weight
not included. Applicable to standard compressors only.
MOTOR
CODE
ENGLISH SI
COMPRESSOR
WEIGHT†
(lb)
STATOR AND
HOUSING
WEIGHT
(lb)
ROTOR AND
SHAFT
WEIGHT
(lb)
END BELL
COVER
WEIGHT
(lb)
COMPRESSOR
WEIGHT†
(kg)
STATOR AND
HOUSING
WEIGHT
(kg)
ROTOR AND
SHAFT
WEIGHT
(kg)
END BELL
COVER
WEIGHT
(kg)
Voltage: 2400-3-60
N 10,287 5929 1212 1021 4666 2689 550 463
P 10,287 6021 1230 1021 4666 2731 558 463
Q 10,287 6112 1248 1021 4666 2772 566 463
R 10,287 6190 1264 1021 4666 2808 573 463
S 10,287 6268 1280 1021 4666 2843 581 463
T 10,287 6259 1280 1021 4666 2839 581 463
Voltage: 3300-3-60
N 10,287 5927 1212 1021 4666 2688 550 463
P 10,287 6019 1230 1021 4666 2730 558 463
Q 10,287 6110 1248 1021 4666 2771 566 463
R 10,287 6187 1264 1021 4666 2806 573 463
S 10,287 6263 1280 1021 4666 2841 581 463
T 10,287 6277 1280 1021 4666 2847 581 463
Voltage: 4160-3-60
N 10,287 6103 1247 1021 4666 2768 566 463
P 10,287 6103 1248 1021 4666 2768 566 463
Q 10,287 6103 1248 1021 4666 2768 566 463
R 10,287 6185 1264 1021 4666 2805 573 463
S 10,287 6268 1280 1021 4666 2843 581 463
T 10,287 6268 1280 1021 4666 2843 581 463
Voltage: 6900-3-60
N 10,287 6558 1316 1021 4666 2975 600 463
P 10,287 6559 1316 1021 4666 2975 600 463
Q 10,287 6559 1316 1021 4666 2975 600 463
R 10,287 6566 1316 1021 4666 2978 600 463
S 10,287 6574 1316 1021 4666 2982 600 463
T 10,287 6604 1351 1021 4666 2996 613 463
Voltage: 11000-3-60
N 10,287 6587 1351 1021 4666 2988 613 463
P 10,287 6587 1351 1021 4666 2988 613 463
Q 10,287 6587 1351 1021 4666 2988 613 463
R 10,287 6716 1385 1021 4666 3036 628 463
S 10,287 6844 1419 1021 4666 3104 644 463
T 10,287 6844 1419 1021 4666 3104 644 463
Voltage: 13800-3-60
N 10,287 6554 1351 1021 4666 2973 613 463
P 10,287 6554 1351 1021 4666 2973 613 463
Q 10,287 6554 1351 1021 4666 2973 613 463
R 10,287 6709 1385 1021 4666 3043 628 463
S 10,287 6864 1419 1021 4666 3113 644 463
T 10,287 6864 1419 1021 4666 3113 644 463
