Carrier 24ABC6 User Manual

10
DIMENSIONS -- SI
B
76.2
K
8.0
L
C
88.9
47.6
N
P
M
E
F
G
A
208-230-1-60
230-1-60
208/230-3-60
460-3-60
UNIT SERIES
ELECTRICAL
CHARACTERISTICS
ABCDEFGKLMNP
OPERATING
WEIGHT (Kgs)
SHIPPING
WEIGHT (Kgs)
SHIPPING
DIMENSIONS (L x W x H)
24ABC618 1 X O O O
24ABC624 0 X O O O 792.2 719.2 95.2 19.0 166.7 627.1 231.8 71.4 12.7 406.4 406.4 330.2 66.5 82.8 822.3 X 901.7 X 827.1
24ABC630 0 X O O O 792.2 820.8 95.2 19.0 166.7 627.1 231.8 71.4 12.7 393.7 406.4 362.0 69.3 85.2 822.3 X 901.7 X 912.8
24ABC636 0 X O O O 889.0 719.2 98.4 22.2 166.7 722.3 231.8 74.6 15.9 406.4 406.4 330.2 74.8 92.5 917.6 X 998.6 X 827.1
24ABC642 0 X O O O 889.0 993.8 98.4 22.2 166.7 722.3 231.8 74.6 15.9 419.1 444.5 444.5 96.4 115.2 917.6 X 998.6 X 1085.8
24ABC648 0 X O O O 889.0 820.8 98.4 22.2 166.7 722.3 231.8 74.6 15.9 431.8 444.5 362.0 104.8 124.3 917.6 X 998.6 X 912.8
24ABC660 0 X O O O 889.0 1166.8 98.4 22.2 166.7 722.3 231.8 74.6 15.9 419.1 431.8 412.8 123.4 140.6 917.6 X 998.6 X 1258.9
654.0 728.7 95.2 19.0 112.7 539.8 198.4 71.4 12.7 346.1 342.9 323.9 56.7 69.9 682.6 X 763.6 X 827.1
UNIT SIZE
MINIMUM
MOUNTING PAD
DIMENSIONS
18 660.4 X 660.4
24,30 800.1 X 800.1
36 THRU 60 889.0 X 889.0
AIR DISCHARGE
AIR DISCHARGE
SQ.
AIR IN
VAPOR LINE CONN.
D
9.53
LIQUID LINE CONN.
AIR IN
AIR IN
AIR IN
9.53 TIEDOWN KNOCKOUTS
(2) PLACES
FIELD CONTROL
SUPPLY CONN.
22.23 HOLE
FIELD POWER SUPPLY CONN.
22.23 HOLE WITH
28.58 KNOCKOUT
X = YES O = NO
NOTES: 1. ALLOW 610.0 CLEARANCE TO SERVICE SIDE OF UNIT, 1219.2 ABOVE UNIT, 152.4 ON ONE SIDE, 304.8 ON REMAINING SIDE, AND 609.6 BETWEEN UNITS FOR PROPER AIRFLOW. 2. MINIMUM OUTDOOR OPERATING AMBIENT IN COOLING MODE IS 13° C, MAX. 52°C. 3. SERIES DESIGNATION IS THE 10TH POSITION OF THE UNIT MODEL NUMBER. 4. CENTER OF GRAVITY . 5. ALL DIMENSIONS ARE IN "MM" UNLESS NOTED.
24ABC6
