Carrier 24ABC6 User Manual

2
MODEL NUMBER NOMENCLATURE
12 3 4 5 6 78 9 10 11 12 13
N N A A A/N N N N A/N A/N A/N N N
24 A B C 6 36 A 0 0 3 0
Product
Series
Product
Family
Tier
Major
Series
SEER
Cooling
Capacity
Grille
Variations
Open Open Voltage Series
24=AC A=RES AC B=Base C=Pur on 6=16 SEER
A=Dense
W=Standard
0=Not
Defined
0=Not
Defined
3=208/230---1
0=
Original
Series
the environmentally sound refrigerant
REGISTERED
ISO 9001:2000
This product has been designed and manufactured to
meet Energy Star® criteria for energy efficiency when
matched with appropriate coil components. However,
proper refrigerant charge and proper air flow are critical
to achieve rated capacity and efficiency. Installation of
this product should follow all manufacturing ref rigerant
charging and air flow instructions. Failure to confirm
proper charge and air flow may reduce energy
efficiency and shorten equipment life.
Use of the AHRI Certified
TM Mark indicates a
manufacturer’s
participation in the
program For verification
of certification for individual
products, go to
www.ahridirectory.org.
STANDARD FEATURES
Feature 18 24 30 36 42 48 49 60
Puron Refrigerant X X X X X X X X
Maximum SEER * 16.0 16.0 16.5 16.5 16.0 16.0 16.0 16.0
Scroll Compressor X X X X X X X X
FieldInstalledFilterDrier X X X X X X X X
Front Seating Service Valves X X X X X X X X
Internal Pressure Relief Valve X X X X X X X X
Internal Thermal Overload X X X X X X X X
Long Line capability X X X X X X X X
Low Ambient capability with Kit X X X X X X X X
* With approved combinations
X=Standard
PHYSICAL DATA
UNIT SIZE--- VOLTAGE, SERIES 18--- 31 24--- 30 30--- 30 36--- 30 42--- 30 48--- 30 60--- 30
Operating Weight lb (kg)
125
(56.7)
147
(66.5)
153
(69.3)
165
(74.8)
213
(96.4)
231
(104.8)
272
(123.4)
Shipping Weight lb (kg)
154
(69.9)
183
(82.8)
188
(85.2)
204
(92.5)
254
(115.2)
274
(124.3)
310
(140.6)
Compressor Type Scroll
REFRIGERANT Puron® (R ---410A)
Control TXV (Puron® Hard Shutoff)
Charge lb (kg)
4.60
(2.09)
6.00
(2.72)
6.81
(3.09)
7.00
(3.18)
8.62
(3.91)
10.50
(4.76)
14.50
(6.58)
COND FAN Propeller Type, Direct Drive
Air Discharge Vertical
Air Qty (CFM) 1881 2614 2614 3223 3810 4046 4046
Motor HP 1/12 1/10 1/ 10 1/ 12 1/5 1/ 4 1/4
Motor RPM 1100 1100 1100 800 800 800 800
COND COIL
Face Area (Sq ft) 11.50 15.10 17.20 17.60 25.15 20.10 30.15
Fins per In. 25 25 25 25 25 20 20
Rows 1 1 1 1 1 2 2
Circuits 3 4 4 4 6 7 8
VALVECONNECT.(In.ID)
Vapor 3/4 3/4 3/4 7/8 7/8 7/8 7/8
Liquid 3/8 3/8 3/8 3/8 3/8 3/8 3/8
REFRIGERANT TUBES (In. OD)
Rated Vapor* 3/4 7/8 1 --- 1 / 8
Max Liquid Line { 3/8
* Units are rated with 25 ft (7.6 m) of lineset length. See Vapor Line Sizing and Cooling Capacity Loss table when using other sizes and lengths of lineset.
Note: See unit Instal lation Instruction for proper install a tion.
{ See Liquid Line Sizing For Cooling Only Systems with Puron Refrigerant tables.
