DETAILED COOLING CAPACITIES# (CONT.)
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Total
System
KW**
Capacity MBtuh
Total
System
KW**
Capacity MBtuh
Total
System
KW**
Capacity MBtuh
Total
System
KW**
Capacity MBtuh
Total
System
KW**
Capacity MBtuh
Total
System
KW**
Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
24ABC642A**30 Outdoor Section With CNPV*4324A** Indoor Section
1225
72 (22.2) 49.58 24.05 2.77 47.31 23.28 3.07 44.88 22.46 3.42 42.30 21.59 3.80 39.58 20.70 4.23 36.71 19.77 4.70 67 (19.4) 45.17 29.64 2.75 43.10 28.86 3.05 40.90 28.04 3.38 38.55 27.18 3.76 36.07 26.27 4.19 33.47 25.33 4.66
63 (17.2)†† 41.97 28.52 2.74 40.06 27.75 3.03 38.02 26.93 3.36 35.83 26.06 3.74 33.53 25.16 4.17 31.10 24.21 4.64
62 (16.7) 41.32 35.16 2.74 39.49 34.36 3.03 37.56 33.49 3.36 35.65 35.65 3.74 33.78 33.78 4.17 31.76 31.76 4.64 57 (13.9) 40.45 40.45 2.73 38.96 38.96 3.03 37.34 37.34 3.36 35.60 35.60 3.74 33.73 33.73 4.17 31.72 31.72 4.64
1400
72 (22.2) 50.40 25.29 2.85 48.02 24.50 3.15 45.48 23.66 3.49 42.82 22.79 3.87 39.99 21.88 4.30 37.02 20.94 4.77 67 (19.4) 45.95 31.63 2.82 43.80 30.84 3.12 41.50 30.00 3.46 39.07 29.12 3.84 36.51 28.20 4.26 33.83 27.23 4.74
63 (17.2)†† 42.74 30.38 2.81 40.75 29.59 3.10 38.61 28.75 3.44 36.36 27.87 3.82 33.97 26.94 4.24 31.47 25.96 4.71
62 (16.7) 42.31 37.80 2.81 40.55 40.55 3.10 38.82 38.82 3.44 36.94 36.94 3.82 34.93 34.93 4.25 32.78 32.78 4.72 57 (13.9) 42.10 42.10 2.81 40.50 40.50 3.10 38.76 38.76 3.44 36.89 36.89 3.82 34.89 34.89 4.25 32.74 32.74 4.72
1575
72 (22.2) 50.98 26.46 2.92 48.52 25.66 3.22 45.91 24.82 3.56 43.16 23.93 3.95 40.25 23.01 4.37 37.22 22.06 4.85 67 (19.4) 46.53 33.54 2.90 44.31 32.73 3.19 41.95 31.88 3.53 39.45 30.98 3.91 36.83 30.02 4.34 34.11 29.02 4.81
63 (17.2)†† 43.31 32.15 2.88 41.25 31.35 3.17 39.06 30.49 3.51 36.74 29.58 3.89 34.30 28.62 4.31 31.77 27.60 4.78
62 (16.7) 43.52 43.52 2.88 41.82 41.82 3.18 39.96 39.96 3.52 37.98 37.98 3.90 35.86 35.86 4.33 33.58 33.58 4.80 57 (13.9) 43.46 43.46 2.88 41.76 41.76 3.18 39.91 39.91 3.52 37.93 37.93 3.90 35.81 35.81 4.33 33.55 33.55 4.80
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
*CNPV*4324A** 1.00 1.00
CAP**4221A** 0.96 1.01 CAP**4224A** 0.96 1.01 CAP**4817A** 0.99 0.99 CAP**4821A** 0.98 0.98 CAP**4823A** 0.98 0.98 CAP**4824A** 0.98 0.98 CAP**6021A** 1.00 1.00 CAP**6024A** 1.00 1.00 CAP**6025A** 1.00 1.00
CNPF*4818A** 0.98 0.98
CNPH*4221A** 0.96 0.96 CNPH*4321A** 1.00 1.00 CNPH*4821A** 0.99 0.99 CNPH*6024A** 1.00 1.00
CNPV*4217A** 0.98 0.98 CNPV*4221A** 0.96 0.96 CNPV*4821A** 0.99 0.99 CNPV*4824A** 0.99 0.99 CNPV*6024A** 1.00 1.00
CSPH*4212A** 0.99 0.99 CSPH*4812A** 0.99 0.99 CSPH*6012A** 1.00 1.00
FB4CNF042 0.99 0.95 FB4CNF048 0.99 0.91
FE4AN(B,F)003 0.96 0.89 FE4AN(B,F)005 0.99 0.91
FE4ANB006 1.00 0.92 FE5ANB004 1.00 0.92
FV4BN(B,F)003 0.96 0.89 FV4BN(B,F)005 0.99 0.91
FV4BNB006 1.00 0.92
FV4CN(B,F)003 0.96 0.89 FV4CN(B,F)005 0.99 0.91
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
FV4CNB006 1.00 0.92
FX4CN(B,F)042 0.99 0.95 FX4CN(B,F)048 1.00 0.92 FX4CN(B,F)060 1.00 1.00 FX4DN(B,F)043 0.99 0.95 FX4DN(B,F)049 1.01 0.93
FY4ANB060 1.00 1.00
FY4ANF042 0.98 1.02 FY4ANF048 0.99 0.99
FY5BNF042 0.98 0.94 FY5BNF048 1.00 0.96
CAP**4817A** 0.98 0.94 58CV(A,X)070---12
CNPH*4221A** 0.95 0.91 58CV(A,X)070---12 CNPH*4321A** 0.98 0.94 58CV(A,X)070---12 CNPH*4821A** 0.98 0.94 58CV(A,X)070---12 CNPH*6024A** 0.99 0.91 58CV(A,X)070---12
CNPV*4217A** 0.96 0.93 58CV(A,X)070---12
CSPH*4212A** 0.98 0.94 58CV(A,X)070--- 12 CSPH*4812A** 0.98 0.94 58CV(A,X)070--- 12 CSPH*6012A** 0.99 0.91 58CV(A,X)070--- 12
CAP**4221A** 0.95 0.88 58CV(A,X)090---16 CAP**4817A** 0.98 0.90 58CV(A,X)090---16 CAP**4821A** 0.98 0.90 58CV(A,X)090---16 CAP**6021A** 0.99 0.91 58CV(A,X)090---16
CNPH*4221A** 0.96 0.93 58CV(A,X)090---16 CNPH*4321A** 0.99 0.91 58CV(A,X)090---16 CNPH*4821A** 0.98 0.90 58CV(A,X)090---16 CNPH*6024A** 0.99 0.91 58CV(A,X)090---16
CNPV*4217A** 0.96 0.93 58CV(A,X)090---16 CNPV*4221A** 0.96 0.93 58CV(A,X)090---16 CNPV*4821A** 0.98 0.90 58CV(A,X)090---16
CSPH*4212A** 0.98 0.90 58CV(A,X)090--- 16 CSPH*4812A** 0.98 0.90 58CV(A,X)090--- 16 CSPH*6012A** 0.99 0.91 58CV(A,X)090--- 16
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CAP**4221A** 0.96 0.89 58CV(A,X)110---20 CAP**4224A** 0.96 0.89 58CV(A,X)110---20 CAP**4821A** 0.98 0.90 58CV(A,X)110---20 CAP**4824A** 0.98 0.90 58CV(A,X)110---20 CAP**6021A** 0.99 0.91 58CV(A,X)110---20 CAP**6024A** 0.99 0.91 58CV(A,X)110---20
CNPH*4221A** 0.96 0.93 58CV(A,X)110---20 CNPH*4321A** 0.99 0.91 58CV(A,X)110---20 CNPH*4821A** 0.98 0.90 58CV(A,X)110---20 CNPH*6024A** 0.99 0.91 58CV(A,X)110---20
CNPV*4221A** 0.96 0.93 58CV(A,X)110---20 CNPV*4324A** 0.99 0.91 58CV(A,X)110---20 CNPV*4821A** 0.98 0.90 58CV(A,X)110---20 CNPV*4824A** 0.98 0.90 58CV(A,X)110---20 CNPV*6024A** 0.99 0.91 58CV(A,X)110---20
CSPH*4212A** 0.98 0.90 58CV(A,X)110--- 20 CSPH*4812A** 0.99 0.91 58CV(A,X)110--- 20 CSPH*6012A** 1.00 0.92 58CV(A,X)110--- 20
CAP**4224A** 0.96 0.89 58CV(A,X)135---22 CAP**4824A** 0.98 0.90 58CV(A,X)135---22 CAP**6024A** 0.99 0.91 58CV(A,X)135---22
CNPH*4221A** 0.96 0.89 58CV(A,X)135---22 CNPH*4321A** 0.99 0.91 58CV(A,X)135---22 CNPH*4821A** 0.98 0.90 58CV(A,X)135---22 CNPH*6024A** 0.99 0.91 58CV(A,X)135---22
CNPV*4324A** 0.99 0.91 58CV(A,X)135---22 CNPV*4824A** 0.98 0.90 58CV(A,X)135---22 CNPV*6024A** 0.99 0.91 58CV(A,X)135---22
CSPH*4212A** 0.98 0.90 58CV(A,X)135--- 22 CSPH*4812A** 0.99 0.91 58CV(A,X)135--- 22 CSPH*6012A** 1.00 0.92 58CV(A,X)135--- 22
CAP**4224A** 0.96 0.89 58CV(A,X)155---22 CAP**4824A** 0.98 0.90 58CV(A,X)155---22 CAP**6024A** 0.99 0.91 58CV(A,X)155---22
