52
CONDENSER ONLY RATINGS CONTINUED
SST
°F(°C)
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
55 (12.78) 65 (18.33) 75 (23.89) 85 (29.44) 95 (35.0) 105 (40.56) 115 (46.11) 125 (51.67)
24ABC642A**30
30
( ---1.11)
TCG 37.90 36.20 34.30 32.30 30.10 27.90 25.50 23.00
SDT 69.80 79.20 88.70 98.10 107.40 116.70 125.90 135.10
KW 1.83 2.03 2.26 2.54 2.86 3.22 3.63 4.09
35
(1.67)
TCG 41.90 40.00 37.90 35.70 33.30 30.80 28.30 25.60
SDT 71.20 80.60 89.90 99.20 108.40 117.70 126.80 136.00
KW 1.84 2.04 2.28 2.56 2.88 3.24 3.65 4.10
40
(4.44)
TCG 46.10 44.00 41.70 39.20 36.70 34.00 31.20 28.30
SDT 72.70 81.90 91.20 100.40 109.60 118.70 127.80 136.90
KW 1.85 2.05 2.30 2.58 2.90 3.26 3.67 4.13
45
(7.22)
TCG 50.70 48.30 45.80 43.10 40.20 37.30 34.30 31.10
SDT 74.20 83.30 92.50 101.60 110.80 119.80 128.90 137.90
KW 1.86 2.07 2.32 2.60 2.92 3.29 3.70 4.15
50
(10.0)
TCG 55.50 52.90 50.10 47.10 44.00 40.80 37.50 34.10
SDT 75.80 84.80 93.90 103.00 112.00 121.00 130.00 138.90
KW 1.87 2.09 2.34 2.63 2.95 3.32 3.73 4.19
55
(12.78)
TCG 60.70 57.70 54.60 51.30 47.90 44.40 40.80 37.10
SDT 77.40 86.40 95.40 104.40 113.40 122.30 131.20 140.00
KW 1.89 2.11 2.36 2.66 2.99 3.36 3.77 4.22
24ABC648A**30
30
( ---1.11)
TCG 42.80 40.60 38.30 36.00 33.60 31.10 28.50 25.80
SDT 67.80 77.20 86.60 96.00 105.40 114.70 124.00 133.30
KW 2.00 2.29 2.58 2.87 3.17 3.51 3.90 4.35
35
(1.67)
TCG 47.40 44.80 42.30 39.70 37.10 34.40 31.60 28.60
SDT 69.00 78.30 87.70 97.00 106.30 115.60 124.80 134.10
KW 1.93 2.25 2.56 2.87 3.19 3.53 3.92 4.36
40
(4.44)
TCG 52.30 49.50 46.60 43.80 40.90 37.90 34.90 31.60
SDT 70.40 79.60 88.80 98.00 107.20 116.50 125.70 134.80
KW 1.82 2.18 2.52 2.85 3.19 3.55 3.94 4.38
45
(7.22)
TCG 57.80 54.60 51.40 48.20 45.00 41.70 38.30 34.80
SDT 71.80 80.80 90.00 99.10 108.30 117.40 126.60 135.70
KW 1.68 2.07 2.45 2.81 3.17 3.55 3.95 4.40
50
(10.0)
TCG 63.70 60.10 56.50 52.90 49.40 45.70 42.00 38.10
SDT 73.20 82.20 91.30 100.30 109.40 118.50 127.50 136.50
KW 1.49 1.93 2.34 2.74 3.13 3.53 3.95 4.41
55
(12.78)
TCG 70.10 66.00 62.00 58.00 54.10 50.00 45.90 41.60
SDT 74.70 83.70 92.60 101.60 110.60 119.60 128.50 137.40
KW 1.25 1.74 2.20 2.63 3.06 3.49 3.94 4.41
24ABC660A**30
30
( ---1.11)
TCG 49.90 47.50 45.10 42.40 39.60 36.70 33.50 30.20
SDT 70.90 80.40 89.80 99.20 108.50 117.80 127.00 136.30
KW 2.31 2.60 2.90 3.24 3.61 4.05 4.56 5.17
35
(1.67)
TCG 55.30 52.60 49.80 46.90 43.90 40.70 37.30 33.80
SDT 72.50 81.80 91.20 100.50 109.70 118.90 128.10 137.30
KW 2.31 2.61 2.93 3.27 3.65 4.08 4.59 5.19
40
(4.44)
TCG 61.00 58.00 54.90 51.70 48.40 45.00 41.40 37.60
SDT 74.10 83.40 92.60 101.80 111.00 120.10 129.20 138.30
KW 2.31 2.63 2.95 3.29 3.68 4.12 4.63 5.22
45
(7.22)
TCG 67.20 63.80 60.30 56.90 53.30 49.60 45.70 41.70
SDT 75.80 84.90 94.10 103.20 112.30 121.40 130.40 139.40
KW 2.31 2.64 2.97 3.32 3.71 4.15 4.66 5.25
50
(10.0)
TCG 73.70 70.00 66.20 62.40 58.50 54.50 50.40 46.10
SDT 77.60 86.60 95.70 104.70 113.70 122.70 131.60 140.50
KW 2.31 2.65 2.99 3.35 3.75 4.19 4.70 5.28
55
(12.78)
TCG 80.80 76.60 72.40 68.30 64.00 59.80 55.30 50.70
SDT 79.50 88.40 97.30 106.20 115.20 124.00 132.90 141.60
KW 2.31 2.66 3.02 3.39 3.79 4.24 4.74 5.32
* AHRI listing applies only to systems shown in Combination Ratings table.
KW --- Outdoor Unit Kilowatts Only.
SDT --- Saturated Temperature Leaving Compressor (° F)
SST --- Saturated Temperature Entering Compressor (° F/° C)
TCG --- Gross Cooling C a pacity (1000 Btuh )
24ABC6
