16
CONDENSER ONLY RATINGS* CONTINUED
SST
°F(°C)
CONDENSER ENTERING AIR TEMPER ATURES ° F (° C)
55 (12.78) 65 (18.33) 75 (23.89) 85 (29.44) 95 (35.0) 105 (40.56) 115 (46.11) 125 (51.67)
24ANB136A**31 --- Low
30
( ---1.11)
TCG 20.80 20.30 19.80 19.10 18.30 17.30 16.00 14.50
SDT 65.00 74.70 84.40 94.10 103.80 113.40 122.90 132.40
KW 1.06 1.20 1.36 1.55 1.78 2.04 2.35 2.71
35
(1.67)
TCG 23.20 22.70 22.00 21.30 20.50 19.40 18.10 16.40
SDT 66.10 75.70 85.40 95.00 104.70 114.20 123.70 133.20
KW 1.04 1.19 1.35 1.54 1.76 2.03 2.33 2.69
40
(4.44)
TCG 25.90 25.20 24.50 23.80 22.80 21.70 20.30 18.60
SDT 67.20 76.80 86.40 96.00 105.60 115.10 124.60 134.00
KW 1.02 1.17 1.34 1.53 1.75 2.02 2.32 2.67
45
(7.22)
TCG 28.70 28.00 27.20 26.40 25.40 24.10 22.70 20.90
SDT 68.40 78.00 87.60 97.10 106.60 116.10 125.50 134.90
KW 0.99 1.15 1.32 1.52 1.74 2.00 2.31 2.66
50
(10.0)
TCG 31.70 30.90 30.10 29.10 28.10 26.80 25.20 23.30
SDT 69.70 79.20 88.70 98.20 107.70 117.10 126.50 135.80
KW 0.97 1.13 1.30 1.50 1.73 1.99 2.30 2.64
55
(12.78)
TCG 34.90 34.00 33.10 32.10 31.00 29.60 27.90 25.90
SDT 71.10 80.50 90.00 99.40 108.80 118.20 127.50 136.70
KW 0.94 1.11 1.29 1.49 1.72 1.98 2.28 2.63
60
(15.56)
TCG 38.30 37.40 36.40 35.30 34.00 32.50 30.80 28.70
SDT 72.50 81.90 91.30 100.60 110.00 119.30 128.50 137.60
KW 0.91 1.08 1.27 1.47 1.71 1.97 2.27 2.61
24ANB148A**31 --- High
30
( ---1.11)
TCG 37.50 37.30 36.40 35.00 33.30 31.30 29.20 27.00
SDT 69.60 79.40 88.90 98.40 107.70 117.00 126.30 135.70
KW 1.92 2.18 2.45 2.75 3.09 3.48 3.94 4.49
35
(1.67)
TCG 41.80 41.50 40.50 38.90 37.00 34.90 32.70 30.40
SDT 71.20 80.90 90.30 99.60 108.90 118.10 127.40 136.70
KW 1.97 2.22 2.49 2.79 3.13 3.52 3.99 4.53
40
(4.44)
TCG 46.40 45.90 44.70 43.00 41.00 38.80 36.40 34.00
SDT 72.80 82.40 91.70 101.00 110.10 119.30 128.50 137.70
KW 2.01 2.26 2.53 2.83 3.17 3.56 4.03 4.58
45
(7.22)
TCG 51.10 50.50 49.10 47.40 45.20 42.80 40.40 37.80
SDT 74.50 83.90 93.10 102.30 111.40 120.50 129.60 138.80
KW 2.05 2.29 2.56 2.86 3.21 3.61 4.08 4.64
50
(10.0)
TCG 56.00 55.20 53.80 51.80 49.60 47.10 44.50 41.80
SDT 76.10 85.40 94.60 103.70 112.70 121.80 130.80 139.90
KW 2.08 2.32 2.59 2.90 3.25 3.66 4.13 4.70
55
(12.78)
TCG 61.10 60.10 58.50 56.50 54.10 51.50 48.70 45.90
SDT 77.80 87.00 96.10 105.10 114.10 123.00 132.00 141.00
KW 2.10 2.35 2.63 2.93 3.29 3.70 4.19 4.76
60
(15.56)
TCG 66.20 65.10 63.40 61.30 58.80 56.10 53.20 50.20
SDT 79.50 88.60 97.60 106.50 115.40 124.30 133.20 142.10
KW 2.13 2.38 2.65 2.97 3.33 3.75 4.25 4.82
24ANB148A**31 --- Low
30
( ---1.11)
TCG 26.80 26.60 25.90 24.80 23.30 21.40 19.20 16.70
SDT 66.40 76.10 85.70 95.20 104.50 113.80 123.00 132.20
KW 1.36 1.57 1.80 2.05 2.33 2.65 3.01 3.41
35
(1.67)
TCG 29.80 29.60 28.90 27.80 26.20 24.30 22.00 19.40
SDT 67.60 77.20 86.80 96.20 105.60 114.80 124.00 133.20
KW 1.34 1.55 1.78 2.04 2.32 2.64 3.00 3.40
40
(4.44)
TCG 33.10 32.80 32.10 31.00 29.40 27.40 25.10 22.40
SDT 68.80 78.50 88.00 97.40 106.70 115.90 125.00 134.20
KW 1.31 1.53 1.77 2.02 2.31 2.63 2.99 3.39
45
(7.22)
TCG 36.60 36.40 35.70 34.50 32.90 30.80 28.40 25.60
SDT 70.20 79.70 89.20 98.60 107.80 117.00 126.10 135.20
KW 1.29 1.51 1.75 2.01 2.30 2.62 2.98 3.38
50
(10.0)
TCG 40.40 40.20 39.50 38.30 36.60 34.50 32.00 29.10
SDT 71.60 81.10 90.50 99.80 109.10 118.20 127.20 136.20
KW 1.26 1.49 1.73 2.00 2.29 2.61 2.97 3.37
55
(12.78)
TCG 44.60 44.30 43.60 42.40 40.70 38.60 36.00 33.00
SDT 73.10 82.60 92.00 101.20 110.30 119.40 128.40 137.30
KW 1.23 1.47 1.71 1.98 2.28 2.60 2.96 3.36
60
(15.56)
TCG 49.10 48.80 48.10 46.90 45.10 42.90 40.30 37.10
SDT 74.70 84.10 93.40 102.60 111.70 120.70 129.60 138.40
KW 1.21 1.44 1.70 1.97 2.27 2.59 2.95 3.35
See notes on page 17
24ANB1
