Carrier 24ANB1 Infinity - Page 17

17
CONDENSER ONLY RATINGS* CONTINUED
SST
°F(°C)
CONDENSER ENTERING AIR TEMPER ATURES ° F (° C)
55 (12.78) 65 (18.33) 75 (23.89) 85 (29.44) 95 (35.0) 105 (40.56) 115 (46.11) 125 (51.67)
24ANB160A**31 --- High
30
( ---1.11)
TCG 48.60 46.60 44.60 42.70 40.60 38.20 35.50 32.50
SDT 69.30 78.60 87.90 97.30 106.70 116.10 125.40 134.60
KW 2.76 3.05 3.37 3.73 4.15 4.62 5.14 5.73
35
(1.67)
TCG 54.50 52.40 50.30 48.30 46.00 43.50 40.60 37.30
SDT 70.60 79.80 89.10 98.40 107.70 117.00 126.30 135.40
KW 2.82 3.10 3.41 3.78 4.19 4.66 5.19 5.79
40
(4.44)
TCG 60.00 57.70 55.50 53.30 50.80 48.00 44.90 41.30
SDT 72.00 81.10 90.30 99.50 108.80 118.00 127.20 136.30
KW 2.89 3.16 3.47 3.82 4.24 4.71 5.24 5.85
45
(7.22)
TCG 65.80 63.40 61.00 58.50 55.80 52.80 49.40 45.50
SDT 73.50 82.50 91.60 100.80 109.90 119.10 128.20 137.20
KW 2.97 3.22 3.52 3.88 4.29 4.76 5.30 5.90
50
(10.0)
TCG 71.90 69.30 66.70 64.00 61.10 57.80 54.00 49.80
SDT 75.00 83.90 93.00 102.00 111.10 120.20 129.20 138.10
KW 3.05 3.29 3.59 3.94 4.35 4.82 5.36 5.96
55
(12.78)
TCG 78.00 75.20 72.40 69.50 66.30 62.70 58.60 54.00
SDT 76.70 85.50 94.40 103.40 112.40 121.40 130.30 139.10
KW 3.13 3.37 3.66 4.00 4.41 4.88 5.42 6.03
60
(15.56)
TCG 84.40 81.50 78.40 75.20 71.60 67.60 63.20 58.30
SDT 78.40 87.20 96.00 104.90 113.80 122.60 131.40 140.10
KW 3.23 3.45 3.74 4.07 4.48 4.95 5.49 6.09
24ANB160A**31 --- Low
30
( ---1.11)
TCG 32.40 31.90 30.70 28.90 26.70 24.10 21.10 18.00
SDT 66.90 76.70 86.20 95.60 104.90 114.10 123.20 132.30
KW 1.92 2.16 2.42 2.71 3.02 3.35 3.71 4.11
35
(1.67)
TCG 36.30 35.60 34.30 32.40 30.10 27.40 24.40 21.10
SDT 68.30 77.90 87.40 96.80 106.00 115.20 124.30 133.30
KW 1.90 2.14 2.41 2.70 3.01 3.35 3.71 4.11
40
(4.44)
TCG 40.40 39.60 38.20 36.20 33.80 31.00 27.80 24.40
SDT 69.60 79.30 88.70 98.00 107.20 116.30 125.30 134.40
KW 1.88 2.12 2.39 2.68 3.00 3.34 3.71 4.11
45
(7.22)
TCG 44.90 43.90 42.40 40.30 37.70 34.80 31.50 27.90
SDT 71.10 80.60 90.00 99.30 108.40 117.40 126.40 135.40
KW 1.85 2.10 2.38 2.67 2.99 3.34 3.71 4.11
50
(10.0)
TCG 49.60 48.50 46.80 44.60 41.90 38.80 35.40 31.70
SDT 72.70 82.10 91.40 100.60 109.60 118.60 127.50 136.40
KW 1.82 2.08 2.36 2.66 2.98 3.33 3.70 4.11
55
(12.78)
TCG 54.60 53.40 51.60 49.20 46.40 43.10 39.50 35.60
SDT 74.30 83.60 92.80 101.90 110.90 119.80 128.70 137.50
KW 1.79 2.05 2.33 2.64 2.97 3.32 3.70 4.10
60
(15.56)
TCG 59.90 58.60 56.60 54.10 51.10 47.70 43.90 39.90
SDT 75.90 85.10 94.30 103.30 112.20 121.00 129.80 138.60
KW 1.75 2.02 2.31 2.62 2.95 3.31 3.69 4.09
* AHRI listing applies only to systems shown in Combination Ratings table.
KW --- Outdoor Unit Kilowatts Only.
SDT --- Saturated Temperature Leaving Compressor (° F)
SST --- Saturated Temperature Entering Compressor (° F/° C)
TCG --- Gross Cooling Ca pacity (1000 Btuh)
24ANB1
