HEAT PUMP HEATING PERFORMANCE CONTINUED
INDOOR AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES ° F (° C)
--- 3 ( --- 1 9 . 4 ) 7 ( ---13.9) 17 ( ---8.3) 27 ( ---2.8) 37 (2.8) 47 (8.3) 57 (13.9) 67 (19.4)
EDB
°F (°C)
CFM
Capacity MBtuh
Tot al
Sys.
KW†
Capacity MBtuh
Tot al
Sys.
KW†
Capacity MBtuh
Tot al
Sys.
KW†
Capacity MBtuh
Tot al
Sys.
KW†
Capacity MBtuh
Tot al
Sys.
KW†
Capacity MBtuh
Tot al
Sys.
KW†
Capacity MBtuh
Tot al
Sys.
KW†
Capacity MBtuh
Tot al
Sys.
KW†
Tot al Integ* To ta l Integ* Tota l Integ* Tot al Integ* To ta l Integ* Tot al Integ* To ta l Integ* Tot al Integ*
25HCB324A30 Outdoor Section With FY4ANF024 Indoor Section
65
(18.3)
700 9.58 8.82 1.52 11.98 11.01 1.59 14.58 13.29 1.66 17.51 15.56 1.75 20.82 18.94 1.86 24.20 24.20 1.96 27.14 27.14 2.06 30.15 30.15 2.17 800 9.77 8.99 1.54 12.19 11.20 1.60 14.81 13.51 1.66 17.80 15.81 1.74 21.14 19.24 1.84 24.17 24.17 1.91 26.94 26.94 2.00 29.60 29.60 2.09 900 9.94 9.15 1.56 12.37 11.37 1.61 15.03 13.70 1.67 18.06 16.04 1.74 21.40 19.47 1.83 24.07 24.07 1.89 26.59 26.59 1.97 28.87 28.87 2.03
70
(21.1)
700 9.29 8.54 1.59 11.70 10.75 1.67 14.30 13.04 1.74 17.18 15.26 1.84 20.47 18.63 1.95 23.95 23.95 2.06 26.95 26.95 2.17 30.01 30.01 2.29 800 9.48 8.72 1.61 11.91 10.94 1.67 14.53 13.25 1.74 17.46 15.51 1.82 20.79 18.92 1.93 24.00 24.00 2.01 26.83 26.83 2.11 29.61 29.61 2.20 900 9.65 8.87 1.63 12.09 11.11 1.69 14.73 13.43 1.75 17.71 15.73 1.83 21.06 19.16 1.92 23.97 23.97 1.99 26.60 26.60 2.07 29.03 29.03 2.15
75
(23.9)
700 8.96 8.24 1.67 11.40 10.48 1.75 14.02 12.78 1.83 16.85 14.97 1.93 20.14 18.33 2.05 23.63 23.63 2.17 26.71 26.71 2.28 29.80 29.80 2.41 800 9.15 8.42 1.68 11.61 10.67 1.75 14.25 12.99 1.83 17.13 15.21 1.91 20.44 18.60 2.03 23.84 23.84 2.12 26.68 26.68 2.22 29.54 29.54 2.32 900 9.33 8.58 1.70 11.80 10.84 1.77 14.45 13.17 1.83 17.37 15.43 1.91 20.71 18.84 2.02 23.82 23.82 2.09 26.53 26.53 2.18 29.10 29.10 2.27
HEATING IN DOOR
MODEL
CAPACITY POWER FURNACE M O DEL
*FY5BNF024 1.00 1.00
FB4CNF024 1.03 1.05 FB4CNF024 1.00 1.02 FB4CNF030 1.03 1.00 FB4CNF030 1.00 0.97
FE4AN(B,F)003 1.00 0.97
FE4ANF002 1.01 0.98 FF1ENP024 1.04 1.08 FF1ENP025 1.03 1.04 FF1ENP030 1.05 1.09 FF1ENP031 1.02 1.02
FV4BN(B,F)003 1.00 0.97
FV4BNF002 1.01 0.98
FX4CNF024 1.03 1.03 FX4CNF030 1.03 0.98
FX4DN(B,F)031 1.02 0.99
FX4DNF025 1.03 1.00
FY4ANF024 1.04 1.08 FY4ANF030 1.04 1.06 FY5BNF024 1.03 1.03 FY5BNF030 1.03 1.02 FY5BNF030 1.00 0.99
CAP**2414A** 1.06 1.08 CAP**2417A** 1.06 1.08 CAP**3014A** 1.02 1.05 CAP**3017A** 1.02 1.05 CAP**3619A** 1.03 1.05
CNPF*2418A** 1.06 1.06
CNPH*2417A** 1.06 1.06 CNPH*3017A** 1.02 1.04
CNPV*2414A** 1.06 1.06 CNPV*2417A** 1.06 1.06 CNPV*3014A** 1.02 1.04 CNPV*3017A** 1.02 1.04
CSPH*2412A** 1.05 1.05 CSPH*3012A** 1.01 1.03
CAP**2414A** 1.02 1.04 58CV(A,X)070--- 12 CAP**3014A** 1.00 1.01 58CV(A,X)070--- 12
CNPH*2417A** 1.02 1.02 58CV(A,X)070 ---12 CNPH*3017A** 1.00 1.00 58CV(A,X)070 ---12
HEATING IN DOOR
MODEL
CAPACITY POWER FURNACE M O DEL
CNPV*2414A** 1.02 1.02 58CV(A,X)070--- 12 CNPV*3014A** 1.00 1.01 58CV(A,X)070--- 12
CSPH*2412A** 1.02 1.02 58CV(A,X)070---12 CSPH*3012A** 0.99 1.00 58CV(A,X)070---12
CAP**2417A** 1.02 1.02 58CV(A,X)090--- 16 CAP**3017A** 1.00 0.99 58CV(A,X)090--- 16
CNPH*2417A** 1.02 1.01 58CV(A,X)090 ---16 CNPH*3017A** 1.00 0.99 58CV(A,X)090 ---16
CNPV*2417A** 1.02 1.01 58CV(A,X)090--- 16 CNPV*3017A** 1.00 0.99 58CV(A,X)090--- 16
CSPH*2412A** 1.02 1.01 58CV(A,X)090---16 CSPH*3012A** 0.99 0.99 58CV(A,X)090---16
CNPH*2417A** 1.02 1.02 58CV(A,X)110 ---20 CNPH*3017A** 1.00 0.99 58CV(A,X)110 ---20
CSPH*2412A** 1.02 1.01 58CV(A,X)110---20 CSPH*3012A** 0.99 0.99 58CV(A,X)110---20
CNPH*2417A** 1.02 1.01 58CV(A,X)135 ---22 CNPH*3017A** 1.00 0.99 58CV(A,X)135 ---22
CSPH*2412A** 1.02 1.01 58CV(A,X)135---22 CSPH*3012A** 0.99 0.99 58CV(A,X)135---22
CNPH*2417A** 1.02 1.01 58CV(A,X)155 ---22 CNPH*3017A** 1.00 0.99 58CV(A,X)155 ---22
CSPH*2412A** 1.02 1.01 58CV(A,X)155---22 CSPH*3012A** 0.99 0.99 58CV(A,X)155---22
CAP**3619A** 1.01 0.99 58HDV040--- ---12
CNPH*2417A** 1.03 1.03 58HDV040--- ---12 CNPH*3017A** 1.01 0.99 58HDV040--- ---12
CNPV*2417A** 1.03 1.02 58HDV040--- --- 12 CNPV*3017A** 1.00 0.98 58HDV040--- --- 12
CSPH*2412A** 1.03 1.02 58HDV040--- --- 12 CSPH*3012A** 1.00 0.99 58HDV040--- --- 12
CAP**3619A** 1.01 0.98 58HDV060--- ---12
CNPH*2417A** 1.03 1.01 58HDV060--- ---12 CNPH*3017A** 1.01 0.98 58HDV060--- ---12
CNPV*2417A** 1.03 1.00 58HDV060--- --- 12 CNPV*3017A** 1.00 0.97 58HDV060--- --- 12
CSPH*2412A** 1.03 1.01 58HDV060--- --- 12 CSPH*3012A** 1.00 0.98 58HDV060--- --- 12
CNPH*2417A** 1.03 0.98 58HDV080--- ---20 CNPH*3017A** 1.00 0.95 58HDV080--- ---20
HEATING IN DOOR
MODEL
CAPACITY POWER FURNACE M O DEL
CSPH*2412A** 1.03 0.98 58HDV080--- --- 20 CSPH*3012A** 0.99 0.95 58HDV080--- --- 20
CNPH*2417A** 1.03 0.99 58HDV100--- ---20 CNPH*3017A** 1.00 0.95 58HDV100--- ---20
CSPH*2412A** 1.03 0.99 58HDV100--- --- 20 CSPH*3012A** 0.99 0.95 58HDV100--- --- 20
CAP**2417A** 1.03 0.99 58ME(B,C)060--- 12 CAP**3017A** 0.96 0.91 58ME(B,C)060--- 12
CNPH*2417A** 1.03 0.99 58ME(B,C)060 ---12 CNPH*3017A** 0.96 0.91 58ME(B,C)060 ---12
CNPV*2417A** 1.03 0.99 58ME(B,C)060--- 12 CNPV*3017A** 0.96 0.91 58ME(B,C)060--- 12
CSPH*2412A** 1.02 0.98 58ME(B,C)060--- 12 CSPH*3012A** 0.96 0.92 58ME(B,C)060--- 12
CAP**2417A** 0.98 0.96 58ME(B,C)080--- 12 CAP**3017A** 0.99 0.95 58ME(B,C)080--- 12
CNPH*2417A** 0.98 0.96 58ME(B,C)080 ---12 CNPH*3017A** 0.96 0.92 58ME(B,C)080 ---12
CNPV*2417A** 0.98 0.96 58ME(B,C)080--- 12 CNPV*3017A** 0.96 0.92 58ME(B,C)080--- 12
CSPH*2412A** 1.02 0.99 58ME(B,C)080--- 12 CSPH*3012A** 0.96 0.93 58ME(B,C)080--- 12
CAP**2417A** 1.03 0.99 58MEB040--- 12 CAP**3017A** 0.96 0.91 58MEB040--- 12
CNPH*2417A** 1.03 0.99 58MEB040--- 12 CNPH*3017A** 0.96 0.92 58MEB040--- 12
CNPV*2417A** 1.03 0.99 58MEB040---12 CNPV*3017A** 0.96 0.92 58MEB040---12
CSPH*2412A** 1.02 0.99 58MEB040---12 CSPH*3012A** 0.96 0.92 58MEB040---12
CNPH*2417A** 1.02 1.02 58MV(B,C)040---14 CNPH*3017A** 1.00 0.99 58MV(B,C)040---14
CSPH*2412A** 1.02 1.01 58MV(B,C)040 ---14 CSPH*3012A** 0.99 0.99 58MV(B,C)040 ---14
CAP**2417A** 1.02 1.03 58MV(B,C)060---14 CAP**3017A** 1.00 1.00 58MV(B,C)060---14
CNPH*2417A** 1.02 1.02 58MV(B,C)060---14 CNPH*3017A** 1.00 0.99 58MV(B,C)060---14
CNPV*2417A** 1.02 1.02 58MV(B,C)060 ---14 CNPV*3017A** 1.00 0.99 58MV(B,C)060 ---14
