Step #4 Wiring Diagram
9
COM
G3/(Y)
G2/(W)
G
R
C
Sample Wiring Diagram
2-Pipe, Low V oltage V alve, Heat Only or Cool Only
COM
G
G3(Y)
G2(W)
R
C
G2
W1
G3
G
V
Y1
Thermostat
24vac
Page 8
24 Volt
Water Valve
Sample Wiring Diagram
2-Pipe, Low Voltage Valve, Cool Only
