Carrier 33CSSP3-FC Installation Instructions

Step #4 Test Operation
8
2-PIPE, HEAT ONLY OR COOL ONLY
• TurnthepowerontotheFanCoilUnitandconrmthatthethermostatis
programmedcorrectlyinsetupsteps#3and#4onpage11oftheOwner’s
Manual.
• IfHeatOnly,presstheMODEbuttonrepeatedlyuntiltheHEAT icon appears
onthedisplay.PresstheUPorDOWNbuttonsuntilthesettemperatureis
10degreesaboveroomtemperature.Thehotwatervalvewillopenandthe
fan will be running.
• IfCoolOnly,presstheMODEbuttonrepeatedlyuntiltheCOOL icon appears
onthedisplay.PresstheUPorDOWNbuttonsuntilthesettemperatureis
10degreesbelowroomtemperature.Thecoldwatervalvewillopenand
the fan will be running.
• PresstheUPbuttonuntilthesetpointisequaltotheroomtemperature.
PresstheFanbuttonrepeatedlyuntilasinglebarappearsnexttotheFan
icon.Conrmthefanisrunningonlowspeed.PresstheFanbuttonagain,
conrmthefanisrunningonmediumspeed.Again,presstheFanbutton,
conrmthefanisrunningathighspeed.PresstheFanbuttononcemore,
thebarsnexttotheFaniconshoulddisappear.
• PresstheMODEbuttonrepeatedlyuntiltheOFF icon appears on the
display.Bothvalveswillbeclosedandthefanwillbeo.

Carrier 33CSSP3-FC Specifications

General

Brand	Carrier
Model	33CSSP3-FC
Category	Thermostat
Language	English
