Carrier 33CSSP3-FC - Selecting Operating Modes; Heating, Cooling, and Auto Modes; Program and Off Modes

Step #4 Wiring Diagram
7
Sample Wiring Diagram
4-Pipe, Low Voltage Valves, Duct Temperature Sensor
& Dry Contact
COM
G3/(Y)
G2/(W)
G
R
C
Sample Wiring Diagram
4-Pipe, Low V oltage V alves, Duct Temperature
Sensor & Dry Contact
COM
G
G3(Y)
G2(W)
BLACK
WHITE
Dry Contact
Duct Sensor
G100-71520307
R
C
R
C
G2
G3
G
RS
H
2
O
Ck1
Y1
W1
HC
Thermostat
24vac
Page 7
24 Volt Water
Valves
Important Note:IfaDuct
sensor is connected to this
thermostat it is suggested
that the fan be programmed
for continuous operation
(step#5,page11ofthe
Owner’sManual)
