Carrier 35E - Page 15

15
D
5’
3’ (MIN)
OR
2/3 OF WALL HEIGHT
Fig. 16 — Typical Space Temperature Sensor
Room Location
Warm
Cool
Fig. 17 — Space Temperature Sensor
(P/N 33ZCT56SPT Shown)
NOTE: Dimensions are in inches.
Fig. 18 — Space Temperature Sensor and Wall
Mounted Humidity Sensor Mounting
2
3
45
61
SW1
SEN
BLK (GND)
RED (SPT)
RED(+)
WHT(GND)
BLK(-)
CCN COM
SENSOR WIRING
Fig. 19 — Space Temperature Sensor Wiring
(33ZCT55SPT)
2
3
45
61
SW1
SEN
SET
Cool Warm
WHT
(T56)
BLK (GND)
RED (SPT)
RED(+)
WHT(GND)
BLK(-)
CCN COM
SENSOR WIRING
JUMPER
TERMINALS
AS SHOWN
Fig. 20 — Space Temperature Sensor Wiring
(33ZCT56SPT)
