Carrier 38C Series User Manual

Combination Matrix and Ratings
T1 T3 T1 T3 T1 T3 T1 T3 T1 T3
38CKPC18DS70 42TPM018-71 230/1/50 Ducted
18,800 16,500 11.8 9.0 1.593 1.833 4,301 1,833 7.5 8.5
38CKPC24DS70 42TPM024-71 230/1/50 Ducted
25,000 21,500 11.8 8.8 2.119 2.443 5,721 2,443 9.5 10.8
38CKPC30DS70 42TPM030-71 230/1/50 Ducted
33,000 28,500 12.0 9.0 2.750 3.167 7,425 3,167 12.0 13.8
38CKPC36DS70 42TPM036-71 230/1/50 Ducted
37,000 32,500 12.2 9.5 3.033 3.421 8,189 3,421 13.2 15.2
38CKPC36DS90 42TPM036-71 400/3/50 Ducted
37,000 32,500 12.2 9.5 3.033 3.421 8,189 3,421 5.0 5.7
38CKPS42DS90 42TPM042-71 400/3/50 Ducted
42,000 39,500 12.7 9.6 3.307 4.115 8,929 4,115 5.5 6.5
38CKPS48DS90 42TPM048-71 400/3/50 Ducted
47,500 43,000 12.2 9.0 3.893 4.778 10,511 4,778 6.6 7.8
38CKPS60DS90 42TPM060-71 400/3/50 Ducted
60,000 51,000 11.8 8.3 5.085 6.145 13,730 6,145 8.5 10.0
38CKPC18DS10 42TPM018-11 240/1/50 Ducted
18,800 16,500 11.5 9.0 1.628 1.833 4,396 1,833 7.5 8.4
38CKPC24DS10 42TPM024-11 240/1/50 Ducted
25,000 21,500 11.8 9.0 2.119 2.389 5,721 2,389 9.5 10.8
38CKPC30DS10 42TPM030-11 240/1/50 Ducted
33,000 28,500 12.0 9.0
2.750 3.167 7,425 3,167 12.0 13.8
38CKPC36DS10 42TPM036-11 240/1/50 Ducted
37,000 32,500 12.2 9.5 3.033 3.421 8,189 3,421 13.2 15.2
38CKPC36DS40 42TPM036-11 415/3/50 Ducted
37,000 32,500 12.2 9.5 3.033 3.421 8,189 3,421 5.0 5.7
38CKPS42DS40 42TPM042-11 415/3/50 Ducted
42,000 39,500 12.7 9.6 3.307 4.115 8,929 4,115 5.5 6.5
38CKPS48DS40 42TPM048-11 415/3/50 Ducted
47,500 43,000 12.2 9.0 3.893 4.778 10,511 4,778 6.6 7.8
38CKPS60DS40 42TPM060-11 415/3/50 Ducted
60,000 51,000 11.8 8.3 5.085 6.145 13,730 6,145 8.5 10.0
Legend for Combination Matrix and Ratings
CFM
— Cubic Feet per Minute
EER
— Energy Efficiency Ratio
kWh/Yr
— kilowatt-hour/Year
FAN
Min Max RLA LRA FLA
38CKPC18DS10 207 253 6.2 48.0 0.52 8.3 15
38CKPC24DS10 207 253 8.6 48.0 0.52 11.3 15
38CKPC30DS10 207 253 11.4 64.0 1.50 15.8 25
38CKPC36DS10 207 253 12.8 64.0 1.50 17.5 30
38CKPC18DS70 207 253 6.2 48.0 0.52 8.3 15
38CKPC24DS70 207 253 8.6 48.0 0.52 11.3 15
38CKPC30DS70 207 253 11.4 64.0 1.50 15.8 25
38CKPC36DS70 207 253 12.8 64.0 1.50 17.5 30
38CKPC36DS40 360 440 4.5 35.0 0.80 6.4 15
38CKPS42DS40 360 440 6.8 43.0 0.80 9.3 15
38CKPS48DS40
360 440 7.1 52.0 0.80 9.7 15
38CKPS60DS40 360 440 9.5 67.1 0.80 12.7 20
38CKPC36DS90 360 440 4.5 35.0 0.80 6.4 15
38CKPS42DS90 360 440 6.8 43.0 0.80 9.3 15
38CKPS48DS90 360 440 7.1 52.0 0.80 9.7 15
38CKPS60DS90 360 440 9.5 67.1 0.80 12.7 20
Legend for Electrical Data Table
EER (Btu/hr) / W Power Input (kW) AMPS
Outdoor Model Indoor Model
Indoor
Type
kWh/Yr
Voltage
Capacity (Btu/hr)
MCA — Minimum Circuit Amps
Electrical Data
MOCP — Maximum Overcurrent Protection
RLA — Rated Load Amps
LRA — Locked Rotor Amps
FLA — Full Load Amps
400/3/50
MCA MOCP
240/1/50
230/1/50
415/3/50
Annual Consumption @ T1 kWh/Year — 2,700 x T1
Outdoor Model
Power Supply
(V/Ph/Hz)
Voltage Compressor
Notes: Testing as per ISO 13253 testing standard at T1 and T3 conditions.
Annual Consumption @ T3 kWh/Year — 1,000 x T3
