Carrier 38CKC - Page 19

19
Detailed cooling capacities*
See notes on pg. 30.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Tot
Sys
Kw**
Capacity
MBtuh†
Tot
Sys
Kw**
Capacity
MBtuh†
Tot
Sys
Kw**
Capacity
MBtuh†
Tot
Sys
Kw**
Capacity
MBtuh†
Tot
Sys
Kw**
Capacity
MBtuh†
Tot
Sys
Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38CKC018-34 Outdoor Section With CC5A/CD5AA018 Indoor Section
525
72 20.25 10.25 1.72 19.55 9.99 1.82 18.70 9.68 1.91 17.66 9.28 2.01 16.52 8.85 2.12 15.29 8.38 2.23
67 18.76 12.50 1.69 17.85 12.14 1.78 16.78 11.71 1.87 15.63 11.22 1.96 14.49 10.74 2.03 13.30 10.25 2.11
62 16.92 14.58 1.66 15.86 14.07 1.74 14.80 13.55 1.80 13.74 13.00 1.87 12.67 12.40 1.94 11.62 11.62 2.02
57 15.57 15.57 1.63 14.83 14.83 1.70 14.06 14.06 1.77 13.27 13.27 1.85 12.47 12.47 1.93 11.63 11.63 2.02
600
72 20.51 10.51 1.76 19.85 10.31 1.85 19.04 10.05 1.95 18.02 9.70 2.05 16.87 9.29 2.16 15.62 8.83 2.27
67 19.17 13.10 1.73 18.26 12.79 1.82 17.20 12.41 1.91 16.02 11.93 2.01 14.82 11.44 2.08 13.58 10.95 2.16
62 17.38 15.51 1.69 16.29 15.01 1.78 15.20 14.44 1.85 14.12 13.82 1.92 13.06 13.06 1.99 12.18 12.18 2.08
57 16.33 16.33 1.68 15.55 15.55 1.76 14.73 14.73 1.83 13.91 13.91 1.91 13.06 13.06 1.99 12.18 12.18 2.08
675
72 20.68 10.74 1.79 20.07 10.58 1.89 19.22 10.34 1.99 18.30 10.08 2.09 17.14 9.69 2.20 15.88 9.26 2.31
67 19.46 13.63 1.77 18.57 13.39 1.85 17.54 13.08 1.95 16.35 12.64 2.05 15.08 12.13 2.13 13.80 11.61 2.21
62 17.74 16.35 1.73 16.67 15.86 1.82 15.57 15.24 1.90 14.48 14.48 1.97 13.57 13.57 2.05 12.67 12.67 2.14
57 17.00 17.00 1.72 16.18 16.18 1.81 15.34 15.34 1.89 14.46 14.46 1.97 13.58 13.58 2.05 12.68 12.68 2.14
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 018 1.00 1.00 40FKA/FK4CNF 002 1.05 0.93
024 1.03 1.01
COILS + 58MVP060-14 VARIABLE SPEED FURNACE
CC5A/CD5AW 024 1.03 1.01 CC5A/CD5AW 024 1.03 0.95
CE3AA 024 1.03 1.02 CE3AA 024 1.03 0.95
CF5AA 024 1.04 1.02 CK5A/CK5BW 024 1.03 0.96
CK3BA 024 1.03 1.02
COILS + 58MVP080-14 VARIABLE SPEED FURNACE
CK5A/CK5BA 018 1.00 1.01 CC5A/CD5AW 024 1.03 0.94
024 1.03 1.02 CE3AA 024 1.03 0.95
CK5A/CK5BW 024 1.03 1.02
COILS + 58U(H,X)V060-12 VARIABLE SPEED FURNACE
F(A,B)4AN(F,C) 018 1.00 0.99 CC5A/CD5AA 018 1.00 0.92
024 1.03 1.01 024 1.03 0.92
FC4BNF 024 1.03 1.01 CE3AA 024 1.03 0.93
FF1DNA 018 1.00 0.97 CK3BA 024 1.03 0.92
024 1.03 1.02 CK5A/CK5BA 018 1.00 0.92
FG3AAA 024 1.03 1.01 024 1.03 0.92
FK4CNF 001 1.03 0.92 —— —
