Carrier 38CKC - Page 20

20
Detailed cooling capacities* continued
See notes on pg. 30.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Tot
Sys
Kw**
Capacity
MBtuh†
Tot
Sys
Kw**
Capacity
MBtuh†
Tot
Sys
Kw**
Capacity
MBtuh†
Tot
Sys
Kw**
Capacity
MBtuh†
Tot
Sys
Kw**
Capacity
MBtuh†
Tot
Sys
Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38CKC024-34 Outdoor Section With CC5A/CD5AA024 Indoor Section
700
72 27.56 13.98 2.36 26.79 13.73 2.50 25.66 13.32 2.63 24.29 12.81 2.77 22.79 12.23 2.92 21.18 11.61 3.06
67 25.58 17.14 2.31 24.41 16.70 2.44 22.96 16.11 2.57 21.42 15.44 2.67 19.89 14.81 2.77 18.36 14.19 2.88
62 23.04 20.01 2.26 21.61 19.33 2.36 20.18 18.62 2.45 18.74 17.87 2.54 17.29 17.12 2.64 16.06 16.06 2.76
57 21.28 21.28 2.21 20.30 20.30 2.31 19.24 19.24 2.41 18.17 18.17 2.51 17.12 17.12 2.63 16.06 16.06 2.76
800
72 27.93 14.38 2.41 27.24 14.21 2.55 26.16 13.87 2.69 24.83 13.41 2.83 23.34 12.89 2.98 21.69 12.28 3.13
67 26.14 18.01 2.37 25.01 17.68 2.49 23.60 17.15 2.62 22.02 16.51 2.75 20.39 15.85 2.85 18.80 15.22 2.96
62 23.70 21.37 2.31 22.24 20.69 2.43 20.80 19.92 2.52 19.25 19.25 2.61 17.98 17.98 2.72 16.89 16.89 2.85
57 22.42 22.42 2.29 21.35 21.35 2.39 20.25 20.25 2.49 19.13 19.13 2.60 17.99 17.99 2.72 16.90 16.90 2.85
900
72 28.17 14.71 2.46 27.53 14.61 2.60 26.50 14.35 2.74 25.21 13.96 2.89 23.73 13.48 3.04 22.08 12.92 3.19
67 26.51 18.75 2.42 25.45 18.56 2.54 24.08 18.11 2.67 22.45 17.51 2.81 20.78 16.84 2.92 19.13 16.17 3.03
62 24.21 22.56 2.36 22.82 21.92 2.48 21.25 21.25 2.58 19.92 19.92 2.69 18.74 18.74 2.80 17.59 17.59 2.93
57 23.35 23.35 2.34 22.25 22.25 2.47 21.12 21.12 2.58 19.93 19.93 2.69 18.75 18.75 2.81 17.60 17.60 2.93
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 024 1.00 1.00 CE3AA 024 0.97 0.96
030 1.01 1.00 030 0.99 0.96
CC5A/CD5AW 024 1.00 1.00 CK3BA 024 0.97 0.96
030 1.01 1.00 030 0.99 0.95
CE3AA 024 1.00 1.01 CK5A/CK5BW 024 0.97 0.96
030 1.01 1.01 030 0.99 0.95
CF5AA 024 1.00 1.00
COILS + 58MVP080-14 VARIABLE SPEED FURNACE
CK3BA 024 1.00 1.01 CC5A/CD5AW 024 0.97 0.94
030 1.01 1.01 030 0.99 0.93
CK5A/CK5BA 024 1.00 1.01 CE3AA 024 0.97 0.95
030 1.01 1.01 030 0.99 0.95
CK5A/CK5BW 024 1.00 1.01 CK3BA 024 0.97 0.94
030 1.01 1.01 030 0.99 0.94
F(A,B)4AN(F,C) 024 1.00 1.00 CK5A/CK5BW 024 0.97 0.94
030 1.01 1.00 030 0.99 0.94
FC4BNF 024 1.00 1.00
COILS + 58U(H,X)V060-12 VARIABLE SPEED FURNACE
030 1.01 1.00 CC5A/CD5AA 024 0.97 0.92
FF1DNA 024 1.00 1.01 030 0.99 0.92
030 1.01 1.02 CC5A/CD5AW 030 0.99 0.92
FG3AAA 024 0.97 0.98 CE3AA 024 0.97 0.93
FK4CNF 001 1.02 0.93 030 0.99 0.93
40FKA/FK4CNF 002 1.03 0.94 CK3BA 024 0.97 0.93
003 1.03 0.92 030 0.99 0.92
COILS + 58MVP060-14 VARIABLE SPEED FURNACE CK5A/CK5BA 024 0.97 0.93
CC5A/CD5AW 024 0.97 0.95 030 0.99 0.92
030 0.99 0.94 CK5A/CK5BW 030 0.99 0.92
