Carrier 38CKC - Page 25

25
Detailed cooling capacities* continued
See notes on pg. 30.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Tot
Sys
Kw**
Capacity
MBtuh†
Tot
Sys
Kw**
Capacity
MBtuh†
Tot
Sys
Kw**
Capacity
MBtuh†
Tot
Sys
Kw**
Capacity
MBtuh†
Tot
Sys
Kw**
Capacity
MBtuh†
Tot
Sys
Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38CKC042-34, 54, 61 Outdoor Section With CC5A/CD5AA042 Indoor Section continued
1225
72 46.29 23.66 3.77 45.13 23.29 4.12 43.60 22.76 4.50 41.68 22.03 4.89 39.58 21.23 5.28 37.31 20.36 5.69
67 42.99 29.14 3.68 41.55 28.63 4.04 39.71 27.86 4.42 37.62 26.97 4.77 35.39 26.03 5.09 32.98 25.04 5.41
62 39.32 34.41 3.62 37.52 33.55 3.95 35.54 32.58 4.25 33.52 31.56 4.56 31.37 30.43 4.87 29.04 29.04 5.16
57
36.80 36.80 3.57 35.42 35.42 3.87 33.95 33.95 4.19 32.40 32.40 4.51 30.77 30.77 4.83 28.98 28.98 5.16
1400
72 46.92 24.37 3.85 45.80 24.09 4.22 44.25 23.63 4.59 42.37 23.00 4.98 40.25 22.23 5.38 37.94 21.40 5.78
67 43.78 30.57 3.77 42.31 30.16 4.12 40.50 29.51 4.50 38.44 28.66 4.89 36.16 27.73 5.22 33.63 26.72 5.54
62 40.13 36.56 3.70 38.39 35.75 4.06 36.39 34.71 4.36 34.34 33.58 4.68 32.18 32.18 4.99 30.24 30.24 5.31
57
38.41 38.41 3.67 37.00 37.00 4.00 35.43 35.43 4.32 33.84 33.84 4.65 32.13 32.13 4.99 30.25 30.25 5.31
1575
72 47.40 25.02 3.94 46.26 24.82 4.30 44.69 24.40 4.68 42.90 23.90 5.07 40.76 23.19 5.47 38.37 22.36 5.86
67 44.32 31.89 3.85 42.90 31.61 4.20 41.12 31.09 4.58 39.04 30.33 4.97 36.74 29.40 5.33 34.16 28.37 5.65
62 40.78 38.51 3.78 39.10 37.73 4.14 37.02 37.02 4.47 35.14 35.14 4.79 33.31 33.31 5.13 31.39 31.39 5.47
57
39.71 39.71 3.76 38.36 38.36 4.12 36.78 36.78 4.45 35.12 35.12 4.79 33.32 33.32 5.13 31.41 31.41 5.47
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CK5A/CK5BT 042 0.99 0.95 CK5A/CK5BW 048 1.00 0.93
048 1.00 0.95
COILS + 58U(H,X)V120-20 VARIABLE SPEED FURNACE
COILS + 58U(H,X)V100-20 VARIABLE SPEED FURNACE CC5A/CD5AW 042 0.99 0.94
CC5A/CD5AW 042 0.99 0.93 048 1.00 0.93
048 1.00 0.92 CE3AA 042 0.99 0.94
CE3AA 042 0.99 0.93 048 1.00 0.95
048 1.00 0.94 CK3BA 042 0.99 0.93
CK3BA 042 0.99 0.93 048 1.00 0.93
048 1.00 0.93 CK5A/CK5BA 042 0.99 0.93
CK5A/CK5BA 042 0.99 0.93 CK5A/CK5BT 042 0.99 0.93
CK5A/CK5BT 042 0.99 0.93 CK5A/CK5BW 048 1.00 0.93
