Detailed cooling capacities* continued
See notes on pg. 30.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Tot
Sys
Kw**
Capacity
MBtuh†
Tot
Sys
Kw**
Capacity
MBtuh†
Tot
Sys
Kw**
Capacity
MBtuh†
Tot
Sys
Kw**
Capacity
MBtuh†
Tot
Sys
Kw**
Capacity
MBtuh†
Tot
Sys
Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38CKC047-30, 50, 60 Outdoor Section With CD5AA048 Indoor Section
1225
72 50.02 25.82 4.10 48.84 25.47 4.45 47.33 24.99 4.84 45.43 24.28 5.27 43.35 23.50 5.74 41.09 22.66 6.25
67 46.57 32.10 4.04 45.06 31.59 4.40 43.20 30.84 4.80 41.17 29.97 5.22 38.92 29.04 5.64 36.47 28.04 6.07
62 42.57 38.09 4.00 40.76 37.19 4.34 38.79 36.20 4.69 36.78 35.14 5.06 34.61 33.94 5.47 32.34 32.34 5.90
57 40.22 40.22 3.97 38.86 38.86 4.29 37.41 37.41 4.65 35.83 35.83 5.04 34.15 34.15 5.45 32.33 32.33 5.90
1400
72 50.64 26.62 4.20 49.53 26.37 4.55 48.01 25.99 4.94 46.12 25.36 5.36 44.02 24.63 5.83 41.73 23.82 6.34
67 47.35 33.74 4.14 45.85 33.38 4.49 44.00 32.72 4.89 41.99 31.93 5.33 39.73 30.99 5.76 37.20 29.99 6.20
62 43.42 40.47 4.08 41.68 39.62 4.45 39.67 38.52 4.80 37.58 37.58 5.18 35.64 35.64 5.59 33.72 33.72 6.03
57 41.99 41.99 4.07 40.56 40.56 4.42 38.99 38.99 4.78 37.38 37.38 5.17 35.66 35.66 5.59 33.73 33.73 6.03
1575
72 51.07 27.31 4.29 49.93 27.16 4.64 48.48 26.88 5.03 46.62 26.35 5.46 44.50 25.66 5.93 42.14 24.88 6.43
67 47.85 35.19 4.23 46.42 35.03 4.58 44.59 34.47 4.97 42.55 33.74 5.41 40.31 32.84 5.88 37.70 31.80 6.31
62 44.09 42.54 4.17 42.40 41.76 4.54 40.46 40.46 4.91 38.68 38.68 5.30 36.87 36.87 5.73 34.90 34.90 6.18
57 43.30 43.30 4.16 41.95 41.95 4.53 40.35 40.35 4.90 38.70 38.70 5.30 36.88 36.88 5.73 34.92 34.92 6.18
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 048 1.00 1.00 CK3BA 060 1.01 0.96
060 1.00 1.00 CK5A/CK5BA 060 1.01 0.96
CC5A/CD5AC 048 0.98 0.99 CK5A/CK5BT 060 1.01 0.96
CC5A/CD5AW 048 1.00 1.00 CK5A/CK5BX 060 1.02 0.96
060 1.02 1.01
COILS + 58MVP120-20 VARIABLE SPEED FURNACE
CE3AA 048 1.00 1.00 CC5A/CD5AA 060 0.99 0.95
060 1.02 1.01 CC5A/CD5AW 060 1.01 0.96
CF5AA 048 1.00 0.99 CE3AA 060 1.01 0.96
CK3BA 048 1.00 1.00 CK3BA 048 0.99 0.95
060 1.02 1.01 060 1.01 0.96
CK5A/CK5BA 048 1.00 1.00 CK5A/CK5BA 048 0.99 0.95
060 1.02 1.01 060 1.01 0.96
CK5A/CK5BT 048 1.00 1.00 CK5A/CK5BT 048 0.99 0.95
060 1.02 1.01 060 1.01 0.96
CK5A/CK5BW 048 1.00 1.00 CK5A/CK5BW 048 0.99 0.95
CK5A/CK5BX 060 1.02 1.01 CK5A/CK5BX 060 1.02 0.96
F(A,B)4AN(F,B,C) 048 1.01 1.02
COILS + 58U(H,X)V080-16 VARIABLE SPEED FURNACE
060 1.03 1.04 CC5A/CD5AA 048 0.99 0.95
FB4ANB 070 1.05 1.03 CC5A/CD5AC 048 0.98 0.95
FC4BN(F,B) 048 1.01 1.02 CE3AA 048 0.99 0.97
060 1.03 1.04 060 1.01 0.96
FC4BNB 054 1.05 1.02 CK3BA 048 0.99 0.97
070 1.05 1.03 CK5A/CK5BA 048 0.99 0.97
FG3AAA 048 0.98 1.00 CK5A/CK5BT 048 0.99 0.97
060 1.00 1.01
COILS + 58U(H,X)V100-20 VARIABLE SPEED FURNACE
40FKA/FK4CNB 006 1.06 0.94 CC5A/CD5AA 060 0.99 0.93
40FKA/FK4CNF 005 1.03 0.95 CC5A/CD5AW 048 0.99 0.93
COILS + 58MVP080-20 VARIABLE SPEED FURNACE 060 1.01 0.94
CC5A/CD5AA 060 0.99 0.95 CE3AA 048 0.99 0.94
CC5A/CD5AW 060 1.01 0.96 060 1.01 0.94
CE3AA 060 1.01 0.96 CK3BA 048 0.99 0.94
COILS + 58MVP100-20 VARIABLE SPEED FURNACE 060 1.01 0.94
CC5A/CD5AA 060 0.99 0.95 CK5A/CK5BA 060 1.01 0.94
CC5A/CD5AW 060 1.01 0.96 CK5A/CK5BT 060 1.01 0.94
CE3AA 060 1.01 0.96 CK5A/CK5BW 048 0.99 0.94
