Carrier 38HDC024 - Page 17

Fig. 24 — Cooling-Only System (38HDC Shown)
RELAY CHART
COMPRESSOR K13
THERMISTOR EQUIVALENCE
TEMPERATURE RESISTANCE
°F °C V
95 35 6,500
72 22 11,400
32 0 32,500
ALL THERMISTORS IN THE 40QN SYSTEMS ARE
IDENTICAL TO EACH OTHER
17
