38MAR-04SI Specifications subject to change without notice. 5
DIMENSIONS (CONT)
Fig. 5 — Size 18K
33.69 in (856mm)
21.28 in (540mm)
33.19 in (843mm)
2.61 in (66mm)
2.80 in (71mm)
13.80 in (351mm)
0.47 in (12mm)
0.51 in (13mm)
13.69 in (348mm)
2.39 in (61mm)
3.64 in (92mm)
14.84 in (377mm)
14.84 in (377mm)
27.68 in (703mm)
