Carrier 38MGRQ18B 3 Series - DIAGNOSIS AND SOLUTION: IPM Module Testing; Bridge Rectifier and IPM Module Testing

46 Specifications subject to change without notice. 38MGR-04SM
DIAGNOSIS AND SOLUTION (CONT)
Fig. 54 — Bridge Rectifier (for 2-zone/3-zone) and IPM Module (for 2-zone/3-zone)
Fig. 55 — IPM Board (for 4-zone)
Bridge rectifier
(
for 2-zone/3-zone
)
IPM Module
(
for 2-zone/3-zone
)
IPM board
(for 4-zone)
