27
OPERATION
TIMER PERIOD SELECTION
PREHEAT OR DEFROST
IN PROGRESS
SELECTED TEMPERATURE
SELF-DIAGNOSTIC CODES
AUTO MODE
Fig. 21 – Unit Display
Table 21 – Signal Receiver Functions
ION indication lamp(optional function)：This lamp illuminates when Clean Air feature is activated.
DEFROST indication lamp(For cooling & heating models only): Lights up when the air conditioner starts defrosting automatically or when
the warm air control featur e is activated in h eating operation.
OPERATION indication lamp: This lamp illuminates when the air conditioner is in operation.
TIMER indication lamp：Lights up during Timer operation.
Temperature indicator：Displays the temperature settings when the air conditioner is operational. Displays the malfunction code.
